Siemens 6AV7861-3AA00-2AA0 SIMATIC FP Flat Panel

SKU 6AV7861-3AA00-2AA0

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Siemens
  • Product No.: 6AV7861-3AA00-2AA0
  • Origin Germany
  • Product Type: Flat Panel
  • Barcode: 85371091
  • Payment: T/T, Western Union
  • Weight: 0.012 kg
  • Dimensions: 62.50 cm x 51.00 cm x 24.00 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Flat Panels SIMATIC FP
Quantità
Call sales Contact

Product Description

Description

The Siemens 6AV7861-3AA00-2AA0 is a SIMATIC Flat Panel 19, designed for industrial visualization and human-machine interface (HMI) applications. This unit features a 19-inch TFT screen with a resolution of 1280 x 1024 pixels, providing clear display capabilities for automation environments. It operates on a 24 V DC power supply and offers versatile connectivity through VGA and DVI-D interfaces. The panel is supplied with a 1.8-meter VGA cable, facilitating immediate integration into existing systems.

Features

  • 19-inch TFT display screen
  • 1280 x 1024 pixel resolution
  • 24 V DC power supply requirement
  • VGA and DVI-D interface support
  • Includes 1.8 m VGA cable

Applications

The Siemens SIMATIC FP Flat Panel is suitable for a range of industrial applications requiring robust and reliable visualization, including:

  • Machine operation and control panels
  • Process monitoring and data display
  • Industrial PC (IPC) visualization
  • Supervisory control and data acquisition (SCADA) systems
  • General human-machine interface (HMI) tasks in manufacturing and automation

Technical Specifications

Brand Siemens
Manufacturer Siemens
Range SIMATIC
Subrange FP
Product Type Flat Panel
Screen Size 19-inch
Display Type TFT
Resolution 1280 x 1024 pixels
Power Supply 24 V DC
Interfaces VGA, DVI-D
Included Cable VGA cable, 1.8 m
Product Phase Phase-Out
Predecessor 6AV7861-3AA00-1AA0
Package Dimensions (Calculated) 62.50 cm x 51.00 cm x 24.00 cm
Shipping Weight 12.00 kg
Commodity Code 85371091
Export Control Regulations (ECCN) EAR99

Installation Guidelines

  1. Safety First: Ensure all power to the installation area is de-energized before beginning any work. Verify with appropriate lockout/tagout procedures.
  2. Mounting: Securely mount the flat panel in the designated enclosure or panel cutout. Ensure adequate ventilation space around the unit to prevent overheating.
  3. Power Connection: Connect the 24 V DC power supply to the appropriate terminals, observing correct polarity. Use shielded cables if specified by system requirements to minimize electrical interference.
  4. Video Connection: Connect the video source (e.g., industrial PC) to the flat panel using either the VGA or DVI-D interface. Utilize the included 1.8 m VGA cable or a suitable DVI-D cable.
  5. Cable Management: Route all cables to prevent strain, sharp bends, or interference with other equipment. Secure cables with ties or clips.
  6. Grounding: Ensure proper grounding of the panel and associated equipment according to local electrical codes and manufacturer recommendations to enhance safety and reduce noise.
  7. Power Up: After all connections are verified, re-energize the system and test the display functionality.
