Siemens 6AV7875-0AC30-1AC0 SIMATIC Panel PC 677B

SKU 6AV7875-0AC30-1AC0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV7875-0AC30-1AC0
Origin Germany
Product Type: Panel PC
Barcode: 84714100
Payment: T/T, Western Union
Weight: 0.017 kg
Dimensions: 67.0 x 83.0 x 11.5 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6AV7875-0AC30-1AC0 is a SIMATIC Panel PC 677B designed for industrial human-machine interface (HMI) and SCADA applications. This unit integrates a 19-inch touch display with a 1280x1024 resolution into a ruggedized chassis powered by an Intel Core 2 Duo T5500 processor. It is equipped with 2 GB of DDR2 RAM and a 160 GB SATA hard disk drive for application and data storage. Connectivity options are extensive, including dual Gigabit Ethernet, USB 2.0, serial, and a PROFIBUS/MPI interface. The system operates on a 24 V DC power supply and comes pre-installed with Windows XP Professional.

Features

19-inch color touch-screen display
Intel Core 2 Duo T5500 processor at 1.66 GHz
2 GB DDR2 system memory
160 GB 3.5-inch SATA Hard Disk Drive (HDD)
Integrated DVD+/-R+/-RW optical drive
Dual 10/100/1000 Mbit/s Ethernet ports
PROFIBUS/MPI communication interface
Front-panel USB port for convenient access
Two available PCI expansion slots
Operates on a 24 V DC power input

Applications

Supervisory Control and Data Acquisition (SCADA)
Human-Machine Interface (HMI) for process visualization
Manufacturing Execution Systems (MES)
Industrial data logging and analysis
Machine control and automation panels

Technical Specifications

System Specifications
Processor	Intel Core 2 Duo T5500, 1.66 GHz
Memory (RAM)	2 GB DDR2
Cache	2 MB SLC
Buffered SRAM	2 MB
Display
Type	19-inch Touch Screen
Resolution	1280 x 1024 pixels
Storage
Hard Drive	160 GB SATA HDD, 3.5-inch
Optical Drive	DVD+-R+-RW
Interfaces & Expansion
Ethernet	2 x 10/100/1000 Mbit/s
USB	4 x USB 2.0 (rear), 1 x USB (front)
Serial	1 x COM1
Fieldbus	PROFIBUS/MPI
Expansion Slots	2 x PCI
Power Supply
Input Voltage	24 V DC
Software
Operating System	Windows XP Professional MUI (de, en, fr, es, it, ja, zh, ko)
Logistics & Compliance
Manufacturer	Siemens
Product Lifecycle Status	Obsolete
Package Dimensions	67.0 x 83.0 x 11.5 cm
Shipping Weight	17.00 kg
Commodity Code	84714100
ECCN	5D992
Country of Origin	Germany (Estimate)

Installation Guidelines

CRITICAL WARNING: RISK OF ELECTRIC SHOCK

Installation, wiring, and maintenance must be performed exclusively by qualified personnel. Disconnect and lock out all power sources before accessing terminals or performing service. Failure to comply can result in severe injury or death.

1 De-energize the control cabinet and all related equipment. Apply appropriate lockout/tagout (LOTO) procedures before beginning installation.
2 Verify the panel cutout dimensions are correct for the Panel PC 677B chassis. Ensure sufficient clearance for ventilation and cable routing.
3 Insert the Panel PC into the cutout from the front. Secure it from the rear using the provided mounting clamps, tightening them evenly to the manufacturer's specified torque to ensure a proper seal.
4 Connect a stable, correctly rated 24 V DC power supply to the designated power input terminals. Verify correct polarity (+/-) before energizing.
5 Connect the functional earth (FE) or protective earth (PE) terminal to the cabinet's ground bus using a low-impedance conductor.
6 Connect network cables to the Ethernet ports and any required fieldbus cables to the PROFIBUS/MPI port. Connect peripheral devices to the USB and serial ports as needed.
7 After verifying all connections are secure, remove LOTO devices and restore power to the cabinet to commission the Panel PC.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What operating system is pre-installed on the 6AV7875-0AC30-1AC0?

This Panel PC comes with Windows XP Professional Multi-User Interface (MUI) pre-installed, supporting languages such as English, German, French, Spanish, Italian, Japanese, Chinese, and Korean.

What is the screen size and resolution of this SIMATIC Panel PC?

It features a 19-inch touch-sensitive display with a native resolution of 1280 x 1024 pixels, suitable for detailed HMI and SCADA visualizations.

What are the primary communication interfaces available?

The unit is equipped with two 10/100/1000 Mbit/s Ethernet ports, four rear USB 2.0 ports, one front-access USB port, one serial (COM1) port, and a PROFIBUS/MPI interface for industrial fieldbus communication.

What are the power supply requirements for this device?

The Siemens SIMATIC Panel PC 677B requires a 24 V DC power source for operation.

Are there any expansion options available for this Panel PC?

Yes, the chassis includes two standard PCI slots for installing additional expansion cards.
