6AV7892-0BG30-1AB0

Siemens

Siemens 6AV7892-0BG30-1AB0 SIMATIC IPC677C Panel PC

SKU 6AV7892-0BG30-1AB0

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Siemens
  • Product No.: 6AV7892-0BG30-1AB0
  • Origin Germany
  • Product Type: Panel PC
  • Barcode: 85371098
  • Payment: T/T, Western Union
  • Weight: 17.45 kg
  • Dimensions: 67.0 x 55.0 x 28.0 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

HMI Panel PCs SIMATIC IPC677C
Quantità
Call sales Contact

Product Description

Description

The Siemens 6AV7892-0BG30-1AB0 is a SIMATIC HMI IPC677C Panel PC designed for demanding visualization and control tasks in industrial environments. This unit integrates a high-performance computer with a responsive operator interface, featuring a 15-inch touch display with 1024 x 768 resolution. It is powered by an Intel Core i7-610E processor and equipped with 4 GB of DDR3 RAM and a 250 GB SATA HDD for robust application performance and data storage. Integrated system monitoring for watchdog, temperature, and fan functions, along with an onboard RAID controller, ensures high operational reliability.

Features

  • 15-inch resistive touch screen for operator control.
  • Intel Core i7-610E dual-core processor (2.53 GHz).
  • Onboard RAID controller for data redundancy.
  • Integrated monitoring for watchdog, temperature, and fan status.
  • Dual Gigabit Ethernet ports for network connectivity.
  • Front-accessible USB 2.0 port for convenient data transfer.
  • Includes a DVD+/-R+/-RW optical drive.
  • Pre-installed with Windows XP Professional SP3 Multi-Language User Interface (MUI).

Applications

  • Human-Machine Interface (HMI) stations for process control.
  • SCADA clients for plant-wide visualization.
  • Data acquisition and logging systems.
  • Machine-level control and monitoring in manufacturing.
  • Industrial PCs for automation cells and production lines.

Technical Specifications

Specification Value
Manufacturer Siemens
Product Series SIMATIC HMI IPC677C
Display 15-inch Touchscreen
Resolution 1024 x 768 pixels
Processor Intel Core i7-610E (2C/4T, 2.53 GHz, 4 MB Cache)
Memory (RAM) 4 GB DDR3 1066 DIMM
Storage 250 GB HDD SATA
Optical Drive DVD+-R+-RW
Ethernet Ports 2 x 10/100/1000 Mbit/s
USB Ports 4 x USB 2.0 (rear), 1 x USB (front)
Serial Port 1 x COM1
Expansion Slots 2 x PCI (free)
Power Supply 110/230 V AC with NAMUR
Operating System Windows XP Professional SP3 MUI (de, en, fr, es, it)
Product Lifecycle Status Phase-Out
Country of Origin Germany (Estimate)
Package Dimensions (Calculated) 67.0 x 55.0 x 28.0 cm
Shipping Weight 17.45 kg

Installation Guidelines

CRITICAL WARNING: Risk of electric shock and equipment damage. Installation must be performed by qualified personnel only. Disconnect all power sources before installation and follow all local safety regulations and Lockout/Tagout (LOTO) procedures.

  1. 1 Ensure the control cabinet is fully de-energized and verified to be at a zero-volt state before beginning work.
  2. 2 Verify the panel cutout dimensions match the IPC677C installation requirements. Ensure the mounting surface is clean, flat, and can support the unit's weight.
  3. 3 Insert the Panel PC into the cutout from the front. Secure it from the rear using the provided mounting clamps, tightening them evenly to the specified torque to ensure a proper seal.
  4. 4 Connect a low-impedance protective earth (PE) conductor to the designated grounding terminal on the PC chassis. This is critical for safety and noise immunity.
  5. 5 Connect the 110/230 V AC power supply cable. Ensure the source voltage matches the power supply rating.
  6. 6 Connect Ethernet, USB, and serial communication cables as required. Use shielded cables for all data lines and ensure proper shield termination to minimize EMI.
  7. 7 After clearing the work area and closing the cabinet door, re-apply power to the cabinet and power on the Panel PC to verify correct startup and operation.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What processor is installed in the 6AV7892-0BG30-1AB0?
This Panel PC is equipped with an Intel Core i7-610E processor, which is a dual-core, four-thread CPU with a base clock speed of 2.53 GHz and 4 MB of cache.
What operating system is pre-installed on this device?
The unit comes with Windows XP Professional Service Pack 3, Multi-Language User Interface (MUI) version, which includes German, English, French, Spanish, and Italian.
What are the primary communication interfaces on this Panel PC?
It includes two 10/100/1000 Mbit/s Ethernet ports, four rear USB 2.0 ports, one front-side USB port, and one serial (COM1) port.
Does this unit have expansion capabilities?
Yes, this configuration includes two free PCI slots available for installing additional expansion cards.
Is a power supply included with this Panel PC?
Yes, it includes an integrated 110/230 V AC power supply unit with NAMUR specifications and a European power cable.
