Description

The Siemens 6AV7894-0BG10-1AB0 is a SIMATIC HMI IPC677C Panel PC designed for industrial visualization and control applications. This unit integrates a 19-inch touch display with a robust PC platform, featuring 2x 10/100/1000 Mbit/s Ethernet ports, 4x USB V2.0 ports, and 1x serial (COM1) interface. It includes onboard watchdog, temperature, and fan monitoring for reliable operation, alongside a RAID controller. The system is powered by a Core i7-610E processor, comes with 2 GB DDR3 1066 DIMM RAM, a 250 GB SATA HDD, and a DVD+-R+-RW optical drive. It offers 2x free PCI slots for expansion and is pre-installed with Windows XP Professional SP3 MUI, supporting multiple languages.

Features

• Integrated 19-inch Touch Display with 1280x1024 resolution
• Front-side USB interface for convenient access
• Dual Gigabit Ethernet connectivity (2x 10/100/1000 Mbit/s)
• Multiple USB V2.0 ports (4x) and one serial (COM1) port
• Integrated watchdog, temperature, and fan monitoring functions
• Onboard RAID controller for data redundancy
• Equipped with a Core i7-610E processor
• 2 GB DDR3 1066 DIMM RAM
• 250 GB SATA Hard Disk Drive
• DVD+-R+-RW optical drive
• Two free PCI expansion slots
• Pre-installed Windows XP Professional SP3 MUI (Multi-User Interface)
• 110/230 V AC power supply unit with NAMUR compatibility

Applications

• Industrial Human-Machine Interface (HMI) systems
• Process visualization and control in manufacturing plants
• Machine operation and monitoring stations
• Data acquisition and processing in industrial environments
• Automation systems requiring integrated PC functionality and display

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. De-energize System: Ensure all power to the system and associated equipment is disconnected before installation or maintenance.
2. Mounting: Securely mount the Panel PC in a suitable enclosure or panel cutout, ensuring adequate space for ventilation and cable routing.
3. Power Connection: Connect the 110/230 V AC power supply unit using the provided Europe power supply cable. Verify correct voltage and grounding.
4. Grounding: Establish a proper protective earth (PE) connection to the Panel PC chassis to ensure electrical safety and minimize electromagnetic interference.
5. Interface Connections: Connect Ethernet cables to the Gigabit ports, USB devices to the USB V2.0 ports, and serial devices to the COM1 port as required by the application.
6. Cable Routing: Route all cables to prevent strain, sharp bends, and interference with other components. Use cable ties for organization.
7. Environmental Considerations: Ensure the operating environment meets the specified temperature and humidity ranges for reliable performance.
8. Initial Power-Up: After all connections are verified, re-energize the system and observe for proper boot-up and functionality.
