Siemens 6ES7153-4BA00-0XB0 SIMATIC ET 200M IM 153-4 PN IO High Feature Interface Module

SKU 6ES7153-4BA00-0XB0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7153-4BA00-0XB0
Origin Germany
Product Type: Interface Modules
Barcode: 85176200
Payment: T/T, Western Union
Weight: 0.3 kg
Dimensions: 5 x 14 x 13 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6ES7153-4BA00-0XB0 is an IM 153-4 PN IO High Feature interface module for the SIMATIC ET 200M decentralized I/O system. This module serves as a gateway, connecting peripheral S7-300 modules to a higher-level controller via PROFINET IO. It is engineered to support a mix of standard, fail-safe, and HART-enabled modules, providing a flexible and scalable solution for process automation. Key capabilities include support for up to 12 S7-300 modules, Shared Device functionality, and the Medium Redundancy Protocol (MRP) to ensure high system availability in critical applications.

Features

Connects up to 12 Siemens S7-300 peripheral modules.
PROFINET IO interface for high-speed industrial communication.
Supports fail-safe (F-modules) for safety-related applications.
Compatible with HART modules for advanced field device diagnostics.
Implements Medium Redundancy Protocol (MRP) for network ring redundancy.
Features Shared Device functionality, allowing I/O access from multiple controllers.

Applications

This interface module is designed for use in a variety of industrial automation environments, including:

Process control systems in chemical, pharmaceutical, and water treatment plants.
Manufacturing and assembly lines requiring high system uptime.
Machine building (OEM) where modular and distributed I/O is required.
Automation systems incorporating functional safety (SIL) requirements.

Technical Specifications

Specification	Value
Manufacturer	Siemens
Part Number	6ES7153-4BA00-0XB0
Product Family	SIMATIC ET 200M
Module Type	IM 153-4 PN IO High Feature Interface Module
Supply Voltage	20.4 VDC to 28.8 VDC
Maximum Modules Supported	12 S7-300 modules
Product Lifecycle Status	Phase-Out
Weight	0.30 kg
Dimensions (W x H x D)	4.0 cm x 12.5 cm x 11.8 cm
Export Control (ECCN)	EAR99
Commodity Code	85176200
Country of Origin	Germany (estimated)
Package Dimensions (Calculated)	5 cm x 14 cm x 13 cm

Installation Guidelines

CRITICAL WARNING: Electrical Hazard. Disconnect and lock out all power sources before installation or removal. Installation must be performed by qualified personnel familiar with applicable codes and standards. Failure to comply can result in severe injury or equipment damage.

1 Ensure the control cabinet is de-energized and verified to be at a zero-volt state using a calibrated multimeter.
2 Mount the module securely onto a standard 35mm DIN rail. Ensure the locking mechanism is fully engaged.
3 Connect the 24 VDC power supply to the designated terminals. Verify correct polarity (+/-) before connection. Use appropriately sized conductors and ensure terminations are secure.
4 Connect the PROFINET IO network cables to the RJ45 ports. Use shielded industrial Ethernet cables to maintain signal integrity.
5 Install the S7-300 peripheral modules onto the backplane bus connectors, starting from the slot adjacent to the interface module.
6 After all connections are verified, remove the lockout/tagout devices and re-energize the system for commissioning and configuration.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the 6ES7153-4BA00-0XB0 module?

It serves as a PROFINET IO interface for the SIMATIC ET 200M distributed I/O system, connecting up to 12 S7-300 peripheral modules to a higher-level controller.

Does this interface module support redundant network configurations?

Yes, it supports the Medium Redundancy Protocol (MRP), which enables it to operate in a ring topology for increased network availability.

Can this module be used in safety-critical applications?

Yes, it is compatible with Siemens fail-safe (F-modules) from the S7-300 series, allowing for the implementation of safety functions.

What is the maximum number of I/O modules that can be connected?

The module supports a maximum of 12 S7-300 series I/O modules, which can be a mix of standard, fail-safe, or HART-enabled types.
