Siemens 6ES7314-6BG03-0AB0 SIMATIC S7-300 Compact CPU

SKU 6ES7314-6BG03-0AB0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7314-6BG03-0AB0
Origin Germany
Product Type: Power supplies
Barcode: 85371091
Payment: T/T, Western Union
Weight: 0.74 kg
Dimensions: 12.00cm x 13.00cm x 12.50cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6ES7314-6BG03-0AB0 is a versatile Compact CPU (CPU 314C-2 PTP) designed for the SIMATIC S7-300 automation system. Combining processing power with integrated I/O functionality, this CPU is ideal for medium-sized automation tasks that require digital/analog control and high-speed counting. It features a 96 KB work memory, integrated 24 V DC power supply, and comprehensive I/O capabilities, reducing the need for external expansion modules.

Features

Integrated I/O: 24 Digital Inputs (DI), 16 Digital Outputs (DO), 4 Analog Inputs (AI), 2 Analog Outputs (AO), and 1 Pt100 temperature input.
Processing: 96 KB work memory for efficient logic execution.
Performance: Four high-speed counters (60 kHz) for precision motion or encoder tasks.
Communication: Integrated MPI and RS485 (PTP) interfaces.
Power: Integrated 24 V DC power supply.
Required Accessories: Requires a Micro Memory Card (MMC) for program storage and 2 x 40-pole front connectors for wiring.

Applications

Integrated machine control and factory automation.
Process control requiring simultaneous analog and digital signal handling.
High-speed pulse counting and position monitoring.
Compact control cabinets where space and module count are restricted.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Range	SIMATIC S7-300
Product Type	Compact CPU
Supply Voltage	20.4–28.8 V DC
Work Memory	96 KB
Digital I/O	24 DI / 16 DO
Analog I/O	4 AI / 2 AO / 1 Pt100
Counters	4 x 60 kHz
Product Phase	Phase-out
Weight	0.74 kg

Installation Guidelines

Mounting: Mount horizontally on an S7-300 standard profile rail. Ensure the CPU is secured using the provided mounting screws.
Wiring: Utilize two 40-pole front connectors to terminate field devices. Always use the appropriate cable cross-sections to prevent voltage drops.
Memory Card: Ensure a compatible Micro Memory Card is inserted into the slot before powering on the CPU to ensure the firmware and project data are loaded correctly.
Grounding: Connect the CPU reference ground to the system common ground to maintain signal integrity, especially for analog input/output loops.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What are the primary I/O capabilities of the 6ES7314-6BG03-0AB0?

It features 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, and 1 Pt100 input.

Does this CPU include a power supply?

Yes, it has an integrated 24 V DC power supply.

Is a memory card required for this unit?

Yes, a Micro Memory Card (MMC) is required for program and data storage.

What is the speed rating of the integrated high-speed counters?

The CPU includes four high-speed counters capable of up to 60 kHz.
