Description

The Siemens 6ES7652-0XX03-1XE1 is a SIMATIC PCS 7 Multi VGA PCI Card designed for industrial display applications within a SIMATIC PCS 7 system. This module facilitates the connection of up to four monitors from a single input unit, featuring an integrated 360MHz RAMDAC and 4 x 32MB RAM. It includes two dual DVI cables for four digital outputs and four adapters for VGA output, providing versatile display connectivity options. This product is currently in an obsolete product phase.

Features

• PCI interface for multi-VGA display capabilities.
• Supports up to four monitors from a single input unit.
• Integrated 360MHz RAMDAC.
• Equipped with 4 x 32MB RAM.
• Includes 2 x dual DVI cables for four digital outputs.
• Includes 4 x adapters for VGA output.
• Designed for integration into SIMATIC PCS 7 systems.

Applications

The Siemens 6ES7652-0XX03-1XE1 is typically deployed in industrial environments requiring multi-monitor display solutions for process visualization and control. Common applications include:

• Industrial control rooms and operator stations.
• Process visualization systems within SIMATIC PCS 7 architectures.
• SCADA and DCS environments needing extended display capabilities.
• Workstations requiring multiple screens for monitoring and data analysis.

Technical Specifications

Connections / Interfaces

• PCI Interface
• DVI Output (Digital)
• VGA Output (Analog)

Installation Guidelines

When installing the Siemens 6ES7652-0XX03-1XE1 Multi VGA PCI Card, adhere to standard industrial practices and safety protocols:

1. De-energize System: Ensure the host PC or industrial computer system is completely powered off and disconnected from the power supply before beginning installation.
2. Static Discharge Precautions: Wear an anti-static wrist strap and work on an anti-static mat to prevent electrostatic discharge (ESD) damage to the card and other components.
3. Locate PCI Slot: Identify an available and compatible PCI expansion slot on the motherboard of the industrial PC.
4. Insert Card: Carefully align the PCI card with the slot and press down firmly and evenly until it is fully seated. Avoid excessive force.
5. Secure Card: Secure the card to the chassis using the retaining screw or clip provided by the PC enclosure.
6. Connect Displays: Connect the desired monitors to the DVI or VGA output ports on the card using the provided cables and adapters.
7. Power On: Reconnect the power supply and power on the system. Install any necessary drivers for the graphics card as prompted by the operating system.
