Siemens 6ES7677-2SB42-0GL0 SIMATIC ET 200SP Open Controller

SKU 6ES7677-2SB42-0GL0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7677-2SB42-0GL0
Origin Germany
Product Type: Open Controller
Barcode: 85371091
Payment: T/T, Western Union
Weight: 3.6 kg
Dimensions: 25.0 x 12.0 x 10.0 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6ES7677-2SB42-0GL0 is a SIMATIC ET 200SP Open Controller, combining the functions of a PC-based controller, HMI, and I/O system into a single compact device. This model, the CPU 1515SP PC2 F, is equipped with 8 GB RAM and a 128 GB CFast card. It comes pre-installed with an embedded Windows operating system, the S7-1500 Failsafe Software Controller (CPU 1505SP F), and WinCC Runtime Advanced software, including a license for 512 PowerTags. This configuration provides a robust platform for demanding automation tasks that require both standard and failsafe control logic alongside integrated visualization.

Features

Combines PLC, HMI, and PC functionality in one device.
Pre-installed with either Windows 10 Pro or Windows 11 Pro (Embedded).
Includes the powerful S7-1500 Failsafe Software Controller for safety applications.
Integrated WinCC Runtime Advanced HMI software with a 512 PowerTags license.
High-speed data processing with 8 GB of RAM.
Ample storage with a 128 GB CFast card, plus an additional SD/MMC card slot.
Includes a restore image on the CFast card for system recovery.

Applications

Complex machine control with integrated safety functions.
Decentralized automation solutions requiring PC-based processing.
Process visualization and control for small to medium-sized plants.
Applications requiring data logging, archiving, and communication with higher-level IT systems.
Automated production lines with integrated quality control and HMI stations.

Technical Specifications

Specification	Value
Manufacturer	Siemens
Product Range	SIMATIC ET 200SP
Product Type	Open Controller
Model Number	6ES7677-2SB42-0GL0
CPU Type	CPU 1515SP PC2 F
Software Controller	S7-1500 Failsafe Software Controller CPU 1505SP F
HMI Software	WinCC Runtime Advanced (512 PowerTags License)
Operating System	Windows 10 Pro or Windows 11 Pro (Embedded)
Memory (RAM)	8 GB
Storage	128 GB CFast
PLM Product Phase	Active
Shipping Weight	3.60 kg
Package Dimensions	25.00 x 12.00 x 10.00 cm
Commodity Code	85371091
Country of Origin	Germany (Estimate)

Connections and Interfaces

Interface / Port	Quantity
CFast Slot	1
SD/MMC Slot	1
ET 200SP Bus Adapter Connection (PROFINET)	1
Ethernet (10/100/1000 Mbit/s)	1
USB 3.0	2
USB 2.0	2
Display Port	1

Installation Guidelines

CRITICAL WARNING: This equipment contains components sensitive to electrostatic discharge (ESD). Use appropriate ESD protection, such as wrist straps and mats, during handling and installation to prevent damage. Disconnect all power sources before installation or maintenance.

1 Verify the control panel is de-energized and locked out according to safety procedures.
2 Mount the ET 200SP Open Controller securely onto the designated DIN rail within the enclosure, ensuring it is correctly oriented.
3 Connect a stable, correctly rated 24 VDC power supply to the designated power terminals. Ensure correct polarity.
4 Establish a low-impedance functional earth (FE) connection to the controller's chassis to minimize electromagnetic interference.
5 Connect network cables to the PROFINET and Ethernet ports. Use shielded cables for all industrial network connections.
6 Connect peripherals such as a monitor via the Display Port and input devices via the USB ports as required for HMI or engineering tasks.
7 Ensure adequate ventilation clearance around the controller as specified by the manufacturer to prevent overheating during operation.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What software is pre-installed on this controller?

It comes with an embedded version of Windows 10 Pro or Windows 11 Pro, the S7-1500 Failsafe Software Controller (CPU 1505SP F), and WinCC Runtime Advanced with a 512 PowerTags license.

What are the main communication interfaces available?

The controller features a dedicated connection for an ET 200SP PROFINET bus adapter, a Gigabit Ethernet port, two USB 3.0 ports, two USB 2.0 ports, and a Display Port for video output.

What is the storage capacity and type?

The unit is equipped with a 128 GB CFast card for the operating system and applications. It also includes a separate SD/MMC card slot for additional data storage.

Is this controller suitable for safety-critical applications?

Yes, it includes the S7-1500 Failsafe Software Controller, which is designed for implementing and executing safety-related automation tasks in compliance with relevant safety standards.

What are the memory specifications for this model?

This Open Controller is configured with 8 GB of RAM to support its PC-based functions, operating system, and automation software.
