Description

The 6ES7314-6CF00-0AB0 is a SIMATIC S7-300 CPU 314C-2DP compact central processing unit equipped with an integrated MPI interface, 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, 1 PT100 input, and 4 fast counters operating up to 60 kHz. This controller includes an integrated DP interface and a 24V DC power supply, offering 48 Kbyte of working memory while requiring an external micro memory card for operation. The 6ES7314-6CF00-0AB0 programmable logic controller delivers robust, high-performance control for demanding industrial automation environments.

Features

• Compact CPU configuration with built-in MPI and DP interfaces
• 24 digital inputs and 16 digital outputs
• 4 analog inputs, 2 analog outputs, and 1 PT100 temperature input
• 4 high-speed counters supporting frequencies up to 60 kHz
• Integrated 24V DC power supply and 48 Kbyte working memory
• Requires a micro memory card for program storage

Applications

• Industrial machinery and automated production lines
• Process control and data acquisition systems
• OEM machine building and discrete manufacturing cells
• Complex automation tasks requiring integrated counting and analog processing

Technical Specifications

Installation Guidelines

• Ensure rack power is completely switched off before mounting or removing the CPU module.
• Insert a compatible micro memory card securely into the designated slot prior to powering up the system.
• Mount the unit onto a standard S7-300 profile rail and secure the fastening screws properly.
• Connect the 24V DC supply and signal wiring while adhering to correct polarity and shielding guidelines.
