Description

The Siemens SINUMERIK 6FC5303-1AF02-8AE0 is a SINUMERIK pushbutton panel MPP 483 HTC-S05 connection MPI/PROFIBUS DP with connection for HT 8 customer-specific variant based on 6FC5303-1AF00-8AA1 engineered by Siemens for CNC operator control environments. Built as a customer-specific variant based on model 6FC5303-1AF00-8AA1, this pushbutton panel features integrated MPI and PROFIBUS DP communication interfaces, along with a dedicated connection port for an HT 8 handheld terminal. With dimensions of 39.50 x 30.00 x 17.00 cm and a weight of 3.00 kg, the 6FC5303-1AF02-8AE0 delivers robust machine tool interaction. This phase-out lifecycle unit is essential for maintaining and supporting legacy SINUMERIK operator panel infrastructure.

Features

• SINUMERIK pushbutton panel MPP 483 HTC-S05 connection MPI/PROFIBUS DP with connection for HT 8 customer-specific variant based on 6FC5303-1AF00-8AA1 design for operator control stations
• MPI and PROFIBUS DP network communication connectivity
• Dedicated connection port for HT 8 handheld terminal integration
• Customer-specific variant based on the 6FC5303-1AF00-8AA1 architecture
• Dimensions of 39.50 x 30.00 x 17.00 cm and 3.00 kg weight
• Phase-out product lifecycle status for legacy system support

Applications

• SINUMERIK CNC machine tool operator control panels
• Industrial automation operator interface stations
• Legacy machine control panel maintenance and retrofits

Technical Specifications

Installation Guidelines

• Mount the pushbutton panel securely into the operator console cutout using standard mounting fixtures to ensure structural stability.
• Connect the MPI or PROFIBUS DP communication cables to the designated ports, ensuring proper network termination and shielding.
• Route the HT 8 handheld terminal connection cable securely to prevent strain and avoid interference with moving parts.
• Verify proper DC power and control wiring integrity prior to system startup.
