Designed for demanding industrial networking environments, the Weidmuller IE-SW-VL05MT-5TX (article number 1504310000) is a managed Fast Ethernet switch engineered to provide reliable data transmission under harsh operational conditions. This 5-port device supports managed switch functionalities, utilizing a store-and-forward data switching architecture to optimize traffic flow and minimize packet loss across local automation networks.
Housed in a rugged IP30-rated metal enclosure, this switch is built to withstand extreme temperatures ranging from -40 degC to 75 degC. It features redundant power inputs to ensure continuous network uptime even in the event of a primary power supply failure. Its compact form factor and support for both DIN rail and panel mounting make it highly adaptable for integration into standard control cabinets.
| Manufacturer | Weidmuller |
| Part Number / Model | IE-SW-VL05MT-5TX (1504310000) |
| Switch Type | Managed |
| Speed | Fast Ethernet |
| Data Switching | Store and Forward |
| MAC Table Size | 2 K |
| Packet Buffer Size | 1 Mbit |
| Voltage Supply | 12/24/48 V DC (2 redundant inputs) |
| Connection Type | 1 removable 6-pin terminal block |
| Housing Material | Metal |
| Protection Degree | IP30 |
| Mounting Type | DIN rail, Panel (with optional mounting kit) |
| Operating Temperature | -40 degC to 75 degC |
| Storage Temperature | -40 degC to 85 degC |
| Humidity | 5% to 95% (non-condensing) |
| Width | 53.6 mm |
| Height | 135 mm |
| Depth | 105 mm |
| Net Weight | 650 g |
| Interface Type | Description |
|---|---|
| RJ45 Ports | 5 x 10/100BaseT(X) auto-negotiation ports |
| Power Connection | 1 removable 6-pin terminal block for redundant power inputs and relay output |
Global Express Shipping
Returns & Warranty
Manufacturer: Weidmuller
Product No.: IE-SW-VL05MT-5TX
Country of origin:Germany
Product Type: Industrial Ethernet Switches
Payment: T/T, Western Union
Weight: 650g
Shipping port: Xiamen
Warranty: 12 months
