Mitsubishi Electric GS2110-WTBD GOT Simple Series Touch Screen HMI

Hanya 10 item tinggal dalam stok

Pengilang: Mitsubishi Electric
No. Produk: GS2110-WTBD
Negara asal:Amerika Syarikat
Jenis Produk: Touch Screen HMIs
Pembayaran: T/T, Western Union
Berat: 1300g
Dimensi: 272 mm x 214 mm x 56 mm
Pelabuhan penghantaran: Xiamen
Jaminan: 12 bulan

Lihat butiran penuh

Description

The GS2110-WTBD is a high-efficiency 10.4-inch widescreen human-machine interface (HMI) designed for operators to monitor and manage industrial automation systems. Belonging to the Mitsubishi Electric GOT Simple Series (part of the GOT2000 family), this terminal features a bright 800 x 480 WVGA TFT color display capable of rendering 65,536 colors. Driven by a solid-state LED backlight, it provides long-term visualization and clarity in industrial control environments.

Equipped with a 9 MB internal flash memory, the GS2110-WTBD accommodates complex screen layouts, alarm logs, and trend graphs. It supports flexible multi-channel communications, incorporating onboard Ethernet, RS-232, RS-422/485, and a USB device interface for direct connection to PLCs, frequency drives, and programming software. With an IP65 rated front panel, the unit is engineered for dust-tight and water-resistant panel-mount installation in challenging processing environments.

Features

10.4-inch WVGA TFT display with a resolution of 800 x 480 pixels
Vivid 65,536-color screen configuration for precise graphic and system monitoring
Maintenance-free, energy-efficient LED backlighting
9 MB of built-in flash memory dedicated to project data storage
Integrated communication suite: Ethernet, RS-232, RS-422/485, and USB Mini-B (Device)
IP65-rated front face protection for deployment in wet or dusty processing zones
Compact, space-saving chassis design with an installation depth of only 56 mm

Applications

Automotive assembly line monitoring and process control
Water and wastewater municipal treatment plant interfaces
Packaging, labeling, and filling machinery control systems
Material handling, conveying, and sorting operations
HVAC and building management system visualization

Technical Specifications

ManufacturerPart Number / ModelSeriesDisplay TypeScreen SizeResolutionDisplay ColorsBacklightInternal MemoryPower Supply VoltageCommunication InterfacesProtection RatingDimensions (W x H x D)Weight

Mitsubishi Electric

GS2110-WTBD (273361)

GOT Simple (GOT2000)

TFT Color LCD

10.4 inches

800 x 480 Pixels (WVGA)

65,536 Colors

LED (non-replaceable)

9 MB (Flash ROM)

24V DC

1x Ethernet (RJ45), 1x RS-232, 1x RS-422/485, 1x USB Mini-B (Device)

IP65 (Front Panel) / IP20 (Rear Case)

272 mm x 214 mm x 56 mm

1.3 kg

Connections and Interfaces

Interface Port	Function Description
Ethernet (RJ45)	Host communication to PLCs, PC configuration, and network connectivity
RS-232	Serial point-to-point connection to controllers, barcode readers, or temperature controllers
RS-422/485	Multi-drop serial communication link for PLC networks
USB Mini-B (Device)	High-speed screen data transfer and configuration using GT Works3 software

Installation Guidelines

Panel Mounting: Insert the device into a clean, rectangular panel cutout of appropriate dimensions (ensure adequate clearance of at least 100mm from nearby heat-generating devices).
Sealing: Tighten the supplied mounting brackets evenly around the perimeter to achieve a secure IP65-compliant seal on the front face. Do not overtighten screws.
Power Supply Wiring: Connect a regulated 24V DC power source. Keep DC power cables separate from high-voltage AC lines to prevent electromagnetic noise induction.
Grounding: Connect the functional ground (FG) terminal of the power connector directly to a dedicated class-D ground point (resistance of 100 ohms or less) using heavy-gauge wire.

Compliance and Certifications

CE (EMC Directive)
UL / cUL Listed
KC (Korean Certification)

Key Features:

#GOT Simple Series #Touch Screen HMIs

What software program is used to configure the GS2110-WTBD touch screen HMI?

The GS2110-WTBD is configured and programmed using the standard Mitsubishi GT Works3 design software package.

What is the supply voltage required for the GS2110-WTBD operator panel?

The GS2110-WTBD operates on a standard nominal voltage of 24V DC.

Does this screen offer multi-channel communication options?

Yes, the unit features multiple integrated communication interfaces, including an Ethernet port, an RS-232 port, an RS-422/485 port, and a USB Mini-B connection.

What is the protection rating of the GS2110-WTBD cabinet interface?

The front panel offers IP65 protection against dust and liquid ingress when properly mounted into a control cabinet, while the rear enclosure is rated at IP20.
