The 171CCS78000 is a high-performance M1 Processor Adapter within the Schneider Electric Modicon Momentum family, engineered to provide centralized intelligence for distributed I/O topologies. Operating at a clock speed of 20 MHz, this processor adapter is designed to snap onto any Momentum I/O base, transforming a simple I/O block into a fully functional, programmable logic controller (PLC).
Featuring dual Modbus communication ports, the 171CCS78000 excels in multi-device networking, allowing for simultaneous communication with HMI panels, variable speed drives, or supervisory systems. Primarily deployed in manufacturing, water wastewater, and material handling, this module is a critical asset for maintaining legacy industrial systems. Although in its phase-out stage, its proven reliability and deterministic control capabilities make it a vital component for facility managers looking to sustain existing automation footprints without expensive re-engineering.
The 171CCS78000 serves as the core "brain" for the modular Momentum platform, integrating processing power with flexible networking:
Dual Modbus Connectivity: Equipped with two independent Modbus RS485 ports, facilitating efficient data exchange and peer-to-peer networking in complex architectures.
20 MHz Processing Core: Delivers sufficient computational speed for medium-complexity logic, PID loops, and rapid I/O refreshing.
Modular "Snap-On" Design: Eliminates the need for a backplane; the adapter mounts directly onto I/O bases, significantly reducing cabinet space requirements.
Standardized Programming: Fully compatible with Schneider Electric legacy programming software, ensuring seamless logic integration for existing Momentum users.
Hardware Efficiency: Compact dimensions and a lightweight design (0.22 kg) allow for high-density mounting in small enclosures or distributed junction boxes.
| Feature | Specification Details |
| Model | 171CCS78000 |
| Brand | Schneider Electric (Modicon) |
| Series | Modicon Momentum |
| Processor Speed | 20 MHz |
| Communication Ports | 2 x Modbus RS485 |
| Module Type | M1 Processor Adapter |
| Product Status | Phase-Out (Legacy Support Available) |
| Net Weight | 0.22 kg |
| Dimensions (cm) | 18 x 26 x 6 (Packaged) |
| Commodity Code | 85389091 |
Can the 171CCS78000 be used as a standalone controller?
Yes, when snapped onto a Momentum I/O base, it functions as a standalone PLC. It does not require a separate rack or power supply module, as it draws power through the I/O base unit.
What is the maximum cable length for the Modbus ports?
For the RS485 Modbus ports, the maximum segment length is 1200 meters (approx. 4000 feet) without a repeater, provided that high-quality shielded twisted-pair cable is used and properly terminated.
Is there a direct replacement for this phase-out module?
While Schneider Electric has moved toward the Modicon M221/M241 series, there is no direct "snap-on" replacement that fits the Momentum I/O bases. Maintaining a stock of 171CCS78000 units is the most cost-effective way to support existing Momentum installations.
Communication Port Wiring and Biasing
When utilizing both Modbus ports, ensure that the network is correctly biased and terminated with 120 Ohm resistors at the physical ends of the trunk. Improper termination on a 20 MHz processor system can lead to intermittent CRC errors and "Module Health" alarms. For noise-heavy environments, always use shielded cables and ground the shield at a single point.
Thermal and Mounting Considerations
Because the 171CCS78000 mounts directly onto the I/O base, it relies on the base for structural integrity. Ensure the locking tabs are fully engaged. In high-vibration applications, we recommend additional DIN rail anchors on both sides of the combined assembly. Avoid installing the module in areas with direct sunlight or near high-heat sources, as excessive heat can degrade the 20 MHz oscillator's accuracy.
Memory Protection
As a legacy M1 adapter, ensure the internal battery or capacitor backup is checked during routine maintenance. If the module is powered down for extended periods without a viable battery, the user program may be lost, requiring a re-download from the original source files.
Global Express Shipping
Returns & Warranty
Manufacturer: Schneider Electric
Product No.: 171CCS78000
Country of origin:France
Product Type: Processor Adapter
Payment: T/T, Western Union
Weight: 220g
Dimensions: 18 cm x 26 cm x 6 cm
Shipping port: Xiamen
Warranty: 12 months
The 171CCS78000 is a high-performance M1 Processor Adapter within the Schneider Electric Modicon Momentum family, engineered to provide centralized intelligence for distributed I/O topologies. Operating at a clock speed of 20 MHz, this processor adapter is designed to snap onto any Momentum I/O base, transforming a simple I/O block into a fully functional, programmable logic controller (PLC).
Featuring dual Modbus communication ports, the 171CCS78000 excels in multi-device networking, allowing for simultaneous communication with HMI panels, variable speed drives, or supervisory systems. Primarily deployed in manufacturing, water wastewater, and material handling, this module is a critical asset for maintaining legacy industrial systems. Although in its phase-out stage, its proven reliability and deterministic control capabilities make it a vital component for facility managers looking to sustain existing automation footprints without expensive re-engineering.
The 171CCS78000 serves as the core "brain" for the modular Momentum platform, integrating processing power with flexible networking:
Dual Modbus Connectivity: Equipped with two independent Modbus RS485 ports, facilitating efficient data exchange and peer-to-peer networking in complex architectures.
20 MHz Processing Core: Delivers sufficient computational speed for medium-complexity logic, PID loops, and rapid I/O refreshing.
Modular "Snap-On" Design: Eliminates the need for a backplane; the adapter mounts directly onto I/O bases, significantly reducing cabinet space requirements.
Standardized Programming: Fully compatible with Schneider Electric legacy programming software, ensuring seamless logic integration for existing Momentum users.
Hardware Efficiency: Compact dimensions and a lightweight design (0.22 kg) allow for high-density mounting in small enclosures or distributed junction boxes.
| Feature | Specification Details |
| Model | 171CCS78000 |
| Brand | Schneider Electric (Modicon) |
| Series | Modicon Momentum |
| Processor Speed | 20 MHz |
| Communication Ports | 2 x Modbus RS485 |
| Module Type | M1 Processor Adapter |
| Product Status | Phase-Out (Legacy Support Available) |
| Net Weight | 0.22 kg |
| Dimensions (cm) | 18 x 26 x 6 (Packaged) |
| Commodity Code | 85389091 |
Can the 171CCS78000 be used as a standalone controller?
Yes, when snapped onto a Momentum I/O base, it functions as a standalone PLC. It does not require a separate rack or power supply module, as it draws power through the I/O base unit.
What is the maximum cable length for the Modbus ports?
For the RS485 Modbus ports, the maximum segment length is 1200 meters (approx. 4000 feet) without a repeater, provided that high-quality shielded twisted-pair cable is used and properly terminated.
Is there a direct replacement for this phase-out module?
While Schneider Electric has moved toward the Modicon M221/M241 series, there is no direct "snap-on" replacement that fits the Momentum I/O bases. Maintaining a stock of 171CCS78000 units is the most cost-effective way to support existing Momentum installations.
Communication Port Wiring and Biasing
When utilizing both Modbus ports, ensure that the network is correctly biased and terminated with 120 Ohm resistors at the physical ends of the trunk. Improper termination on a 20 MHz processor system can lead to intermittent CRC errors and "Module Health" alarms. For noise-heavy environments, always use shielded cables and ground the shield at a single point.
Thermal and Mounting Considerations
Because the 171CCS78000 mounts directly onto the I/O base, it relies on the base for structural integrity. Ensure the locking tabs are fully engaged. In high-vibration applications, we recommend additional DIN rail anchors on both sides of the combined assembly. Avoid installing the module in areas with direct sunlight or near high-heat sources, as excessive heat can degrade the 20 MHz oscillator's accuracy.
Memory Protection
As a legacy M1 adapter, ensure the internal battery or capacitor backup is checked during routine maintenance. If the module is powered down for extended periods without a viable battery, the user program may be lost, requiring a re-download from the original source files.
Global Express Shipping
Returns & Warranty
