ABB 1SAP121000R0071 PM564-RP-ETH AC500 Programmable Logic Controller

SKU PM564-RP-ETH 1SAP121000R0071

In stock

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: PM564-RP-ETH 1SAP121000R0071
Country of origin:China,Germany,India
Product Type: Processor Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 295g
Dimensions: 82 mm x 135 mm x 74 mm (W x H x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The 1SAP121000R0071 PM564-RP-ETH is a compact processor unit designed for Distributed Automation PLCs within the AC500-eCo product family. This programmable logic controller serves as a central processing core in industrial environments, executing control logic with a processing time of 0.00008 ms. Equipped with integrated onboard I/O capabilities, the device features 8 digital inputs, 6 digital outputs, 2 analog inputs, and 1 analog output to interface directly with field instrumentation. For industrial networking and peripheral integration, it provides built-in connectivity via 1 Industrial Ethernet interface and 1 RS485 serial port, alongside 2 option slots for flexible hardware expansion.

Features

Integrated compact CPU module with 142 kB memory size.
Onboard interface selection featuring Industrial Ethernet and RS485 communication ports.
Built-in analog and digital I/O channels for direct process signal handling.
RAM user data memory type designed for dynamic program execution.
Expansion capabilities via two integrated option slots for application-specific hardware modules.

Applications

Distributed automation PLC architectures.
Factory automation and process control monitoring.
Machine-level automation requiring compact digital and analog interfacing.

Technical Specifications

Parameter	Value
Manufacturer	ABB
Product ID	1SAP121000R0071
ABB Type Designation	PM564-RP-ETH
Product Type	PLC-AC500-eCo
Product Main Type	PM564
Model Number	Compact
Controller Processing Time	0.00008 ms
Memory Size	142 kB
Memory Type User Data	RAM
Input Voltage Type	DC
Rated Voltage (Ur)	24 V DC
Supply Voltage	20.4 to 28.8 V DC
Power Consumption (@Pcons)	2.880 W
Number of Digital Inputs	8
Number of Digital Outputs	6
Number of Digital Configurable I/Os	0
Analog Inputs	2
Analog Outputs	1
Industrial Ethernet Interfaces	1
RS-485 Interfaces	1
Option Slots	2
Product Net Width	82 mm
Product Net Height	135 mm
Product Net Depth / Length	74 mm
Product Net Weight	0.295 kg
Gross Weight	0.456 kg
Country of Origin	China, Germany, India

Installation Guidelines

Ensure the DC supply voltage is regulated within the technical threshold of 20.4 to 28.8 V DC to protect internal control circuitry.
Mount the compact enclosure securely onto a standard DIN rail or enclosure panel, maintaining sufficient clearance for adequate airflow and cooling.
Terminate communication lines appropriately, utilizing the Industrial Ethernet or RS485 interfaces depending on network topology demands.
Ground the device according to local electrical codes to mitigate electromagnetic interference (EMI) across processing modules and analog input lines.

FAQ

What is the memory configuration of this PLC module?

The device features a total memory size of 142 kB, utilizing RAM as the user data memory type for logic execution.

What types of integrated communication interfaces are available on the unit?

The module comes equipped with 1 Industrial Ethernet interface and 1 RS-485 serial port, alongside 2 option slots for additional expansion.

What are the specific onboard I/O capabilities of the device?

The unit provides direct field connectivity via 8 digital inputs, 6 digital outputs, 2 analog inputs, and 1 analog output.

What are the acceptable power supply limits for reliable operation?

The module operates on a rated voltage of 24 V DC, with an acceptable supply voltage range between 20.4 V DC and 28.8 V DC.
