Allen-Bradley 1756-L1M2 ControlLogix Processor Module

SKU 1756-L1M2

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Allen-Bradley
Product No.: 1756-L1M2
Country of origin:United States
Product Type: Processor Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 350g
Dimensions: 145 mm x 35 mm x 135 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 1756-L1M2 is a ControlLogix 5550 controller processor module. It provides 1 MB of user-available memory without nonvolatile memory. The module is designed to control local and remote I/O across DeviceNet, ControlNet, and Universal Remote I/O networks. Built with an open-style enclosure, it features Group 1, Class A emissions.

The 1756-L1M2 features an average power dissipation of 4.8 W and an average thermal dissipation of 16.4 BTU/hr. It operates with an average backplane current of 1.05 A at 5V DC and 0.02 A at 24V DC. The controller supports serial communications using 1756-CP3 or 1747-CP3 programming cables and relies on a 1756-BA1 0.59g lithium battery for memory backup.

Features

Integrated ControlLogix 5550 controller architecture
Open-style enclosure construction
Multi-network I/O control across DeviceNet, ControlNet, and Universal Remote I/O
Direct interface with 1756-CP3 and 1747-CP3 serial programming cables
Dedicated battery backup using the 1756-BA1 lithium battery

Applications

Industrial PLC and PAC control systems
Process control across DeviceNet and ControlNet networks
Distributed I/O management and communication routing
General factory automation and machine control

Technical Specifications

Parameter	Value
Manufacturer	Allen-Bradley
Category	PLCs
Product Line	ControlLogix
Part Number	1756-L1M2
Module Type	Processor Module
User Available Memory	1 MB
Expansion Memory	1 MB
Enclosure Type	Open
Isolation Voltage	30V Continuous (Tested to withstand 500V for 60 seconds)
Operating Temperature	0 to 60 degC (32 to 140 Fahrenheit)
Storage Temperature	-40 to 85 degC (-40 to 185 Fahrenheit)
Relative Humidity	5% to 95% noncondensing
Minimum Operating Current	2 mA at 10V DC
Maximum Operating Current	3.5 mA at 30V DC
Maximum Input Current (Off-State)	1.5 mA
Peak Backplane Current (+5V DC)	1.05 A
Peak Backplane Current (+24V DC)	0.02 A
Average Power Dissipation	4.8 W
Maximum Power Dissipation	4.1 W at 60 degC
Average Thermal Dissipation	16.4 BTU/hr
Vibration	10 to 500 Hz, 2.0 G maximum peak acceleration
Operating Shock	30 G peak for 11 ms
Storage Shock	50 G peak for 11 ms
Conducted RF Immunity	10Vrms with 1 kHz sine-wave 80%AM from 150 kHz to 80 MHz
ESD Immunity	6 kV contact discharges, 8 kV air discharges
EFT/B Immunity	+/-2 kV at 5 kHz on communication ports, +/-4 kV at 2.5 kHz on power ports
Radiated RF Immunity	10V/m with 200 Hz 50% Pulse 100%AM at 900 MHz; 10V/m with 1 kHz sine-wave 80%AM from 30 MHz to 1000 MHz
Programming Cable	1756-CP3 or 1747-CP3 serial cable
Battery	1756-BA1 (0.59g lithium)
Weight	12.5 oz. (0.35 kg)
UPC	10612598180988
