Allen-Bradley

Allen-Bradley 1756-SYNCH ControlLogix SynchLink Communication Module

SKU 1756-SYNCH

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley

  • Product No.: 1756-SYNCH

  • Country of origin:United States

  • Product Type: Synchlink Communication Module

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 300g

  • Dimensions: 21.5 x 14.0 x 4.8 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The Allen-Bradley 1756-SYNCH functions as a dedicated, high-speed fiber-optic communication interface that establishes deterministic data broadcasting and system clock synchronization across multiple control platforms. Designed to slot directly into any standard chassis assembly, this SynchLink communication module enables peer-to-peer data consumption between independent controllers, allowing motion axis variables and drive coordination data to be transferred with minimal latency. By managing specialized fiber-optic frames via dedicated physical layer ports, the unit aligns the distributed system time bases required for highly integrated co-dependent automation processes.

Features

  • Deterministic Data Transfer: Delivers synchronous communications with a fixed frame transmission speed of 50 microseconds.
  • Fixed Data Throughput: Runs at a continuous SynchLink data rate of 5 Mbps for real-time motion and control distribution.
  • Optical Multi-Chassis Linkage: Integrates 2 localized fiber-optic cable ports utilizing a 650 nm operating wavelength.
  • Optimized Frame Architecture: Uses a highly structured frame layout containing 3 flag bytes, 1 control byte, 24 data bytes, and a 2-byte cyclic redundancy check (CRC) field for transmission verification.
  • Power Infrastructure Support: Engineered to interface seamlessly within backplanes powered by either standard or redundant power supply modules.

Applications

  • Multi-chassis master/slave system clock synchronization in high-speed manufacturing lines.
  • Coordinated drive systems and real-time motion control distribution across separated industrial racks.
  • Inter-controller consumption of critical motion axis variables without traditional network bandwidth overhead.

Technical Specifications

Parameter Specification
Manufacturer Allen-Bradley / Rockwell Automation
Model Part Number 1756-SYNCH
Module Type SynchLink Communication Module
Product Line ControlLogix
GTIN 10612598275301
UPC 10612598307699
Data Rate / Baud Rate 5 Mbps
Operating Wavelength 650 nm
Frame Processing Speed 50 us
Backplane Current Draw (5.1V DC) 1200 mA
Backplane Current Draw (24V DC) 3 mA (User text context indicates up to 3 mA; raw source parameters note 2.5 mA)
Power Dissipation (Max) 6.2 W
Thermal Dissipation 21.2 BTU/hr
Fiber Medium Compatibility 200-230 micron Hard-Clad Silica (HCS) cable
Fiber Termination Type Versalink V-System
Permissible Cable Length Range 1 - 300 m
Internal Target Wire Size 20 AWG
Operating Enclosure Rating None (open-style)
Operating Temperature Range 0 Celsius to 60 Celsius (32 Fahrenheit to 140 Fahrenheit)
Operating Shock Limits 30g
Country of Origin United States / USA
Shipping Weight (Calculated) 1.00 lbs (0.45 kg)
Package Dimensions (Calculated) 21.5 x 14.0 x 4.8 cm (8.46 x 5.51 x 1.89 in.)

Alternative Models & Compatibility

The 1756-SYNCH module establishes explicit physical-layer communication configurations that dictate the use of specialized 200-230 micron Hard-Clad Silica (HCS) glass lines with Versalink V-System termination. It cannot be directly substituted with standard multi-mode or single-mode LC/ST telecommunication fiber interfaces. For specific layout extensions, approved functional accessories include the 1403-CFxxx fiber-optic pre-assembled cable layouts or the simplex 200 um HCP-M0200T V01RK raw cable lines.

Application Pitfalls & Engineering Notes

A major installation risk involves ignoring fiber-optic link attenuation limits across long physical spans up to the 300 m cap. Ensure the core fiber run is free from tight routing bends that violate minimum radius restrictions, as micro-bending causes massive light loss at the 650 nm operating wavelength, throwing CRC link faults inside the frame parameter checker. Ambient particulates also threaten the interface; because the module uses an open enclosure design, deploying this unit in environments that do not meet clean, dry industrial specifications will foul the transceiver ports, destabilizing the 50 us clock alignment loop.

Installation Guidelines

CRITICAL WARNING: Isolate and completely cut off all primary electrical utilities feeding the hosting control chassis backplane before sliding or uncoupling the communication assembly. Handling module insertion steps while the rack contains active residual voltage risks triggering unexpected backplane noise spikes, communication drops on adjacent nodes, or component degradation.
1
Identify an open slot inside the designated ControlLogix chassis and inspect the internal backplane connector pins for structural alignment.
2
Align the module circuit board with the top and bottom card guides of the chosen slot tracking.
3
Press the module firmly into the slot until the top and bottom housing tabs snap securely flush with the chassis frame.
4
Remove the protective dust caps from the 2 optical ports and clean the transceivers before inserting the Versalink V-System fiber terminations.
5
Secure the fiber-optic cabling in the wire ducting, verifying that the physical link length remains between 1 m and 300 m without strict bends.

FAQ

What specific fiber cable core and connector types are required for this module?

The module requires a 200-230-micron Hard-Clad Silica (HCS) fiber-optic cable completed with a Versalink V-System physical termination connector.

What is the maximum distance supported between connected chassis links?

The certified point-to-point fiber-optic cable run length must be maintained within a structural range of 1 meter to 300 meters maximum.

How much backplane current does the communication link draw during active state execution?

The module draws a high nominal current load of 1200 mA at 5.1V DC, and a minimal auxiliary current draw of 2.5 mA to 3 mA at 24V DC.

What is the continuous synchronization speed of the data link frames?

The module maintains deterministic synchronous system communications executing with a fixed frame speed of 50 microseconds.
