Description

The BECKHOFF CP6733-0000-0060 is an economy built-in Panel PC designed for industrial control, machine-level visualization, and human-machine interface (HMI) tasks. This unit integrates a high-quality 15-inch TFT display with a full alphanumeric keyboard and a single-finger touch screen or touchpad, providing operator interaction and control directly on the factory floor.

Housed in a rugged aluminum front frame with a sheet-steel rear cover, the BECKHOFF CP6733-0000-0060 is engineered for demanding industrial environments. It is powered by an Intel Atom x5-E39xx processor platform and equipped with 4 GB of DDR4 RAM. Operating on a 24 V DC power supply, this built-in Panel PC provides a robust, fanless hardware solution optimal for running TwinCAT automation software.

The unit features versatile connectivity options, including two independent Gigabit Ethernet ports for network segregation or EtherCAT communication, alongside multiple USB ports and a DVI video connection. Built-in pull-out clamping levers allow for quick panel installation and clean integration into control cabinets.

Features

• 15-inch TFT display with a native resolution of 1024 x 768 pixels.
• Integrated front panel featuring a full US-layout alphanumeric PC keyboard and 10 PLC special keys with status LEDs.
• Reliable single-finger touch screen or touchpad navigation.
• Intel Atom x5-E39xx processor technology designed for fanless, low-power industrial operation.
• Standard 4 GB DDR4 RAM configuration.
• CFast slot for secure, high-speed solid-state storage.
• Dual 100/1000BASE-T on-board Ethernet interfaces for separate fieldbus and office networks.
• IP65-rated front panel and IP20-rated rear enclosure protection.
• Integrated pull-out clamping levers for fast mounting without loose components.

Applications

• Machine-level human-machine interface (HMI) and process visualization.
• Industrial PC-based control systems operating with TwinCAT runtime software.
• Production line monitoring, data logging, and operator terminal tasks.
• Embedded control applications requiring physical alphanumeric keyboard entry.

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. Ensure that all power sources are fully de-energized and locked out before starting physical installation.
2. Prepare the control cabinet cutout according to the official mounting dimensions specified for the 15-inch CP6733 series panel.
3. Ensure the sealing gasket on the front panel is correctly seated and free of dirt or damage to maintain the IP65 rating.
4. Insert the Panel PC into the cutout from the front, and secure it from the rear using the integrated pull-out clamping levers. Tighten the levers evenly until the unit is flush.
5. Connect the protective earth ground wire to the designated grounding screw on the sheet-steel rear cover.
6. Connect the 24 V DC power supply lines to the power terminal block.
7. Insert the CFast storage card containing the operating system and TwinCAT configuration.
8. Connect the Ethernet, USB, and display interfaces as required by the application.
9. Apply power and perform commissioning and functional verification checks.

Replacement Recommendations

When replacing an active BECKHOFF CP6733-0000-0060, always back up the existing TwinCAT project files, persistent variable data, and OS configuration from the CFast storage media. Disconnect the 24 V DC power supply before removing the connections or sliding out the pull-out clamping levers. Re-verify the IP65 cabinet seal integrity prior to mounting the replacement Panel PC.
