Description

The BECKHOFF CP7201-0000-0060 is an industrial Economy Panel PC designed for direct mounting arm installation, offering comprehensive mechanical protection and robust processing power. Engineered as an all-in-one HMI and control solution, this Panel PC features a rugged aluminum housing that meets IP65 ingress protection standards, making it highly resilient against dust and water in demanding factory floor environments.

At the core of the BECKHOFF CP7201-0000-0060 is a high-performance motherboard designed for Intel processors, providing the execution speed needed for complex automation and visualization tasks. Thermal management is handled efficiently through a combination of a passive heat sink structure located between the Control Panel and the integrated PC unit, alongside an internal fan that ensures uniform heat distribution across the housing walls.

With its rotatable mounting arm adapter, the system easily integrates with standardized 48 mm tube installation setups, such as those from Rittal and Rolec. The device provides a highly compact physical footprint while maintaining spacious wiring and installation clearance for reliable cable management and continuous operation.

Features

• Rugged aluminum housing with full IP65 rating for high-durability protection against liquid and particulate contamination.
• Integrated rotatable mounting arm adapter, compatible with Rittal and Rolec 48 mm tube systems from both top and bottom entry.
• Advanced cooling design utilizing a passive external heat sink combined with an internal air circulation fan for balanced thermal load.
• Supports multi-core Intel processing architecture on a compact 3.5-inch industrial motherboard.
• Onboard dual Ethernet interfaces (100/1000BASE-T) for robust network integration and control fieldbus architectures.
• Compact wiring area designed to support secure industrial connectors.

Applications

• Human-Machine Interface (HMI) and visualization stations in automotive assembly, packaging, and general manufacturing lines.
• Machine-level control demanding full IP65 physical isolation without a secondary enclosure.
• Operator terminal integration on swing arms, pedestals, or machine frames.

Technical Specifications

Installation Guidelines

1. Pre-Installation Check: Verify the model numbers and voltage requirements before commencing installation. Ensure that the power source matches the 24 V DC input specification.
2. Mounting: Attach the PC securely to a compatible 48 mm tube mounting arm system. Verify that the rotatable adapter is properly locked and that the rotation limits align with operational requirements.
3. Clearance Requirements: Maintain at least 20 cm (7.9 inches) of free space around the unit's cooling structures to prevent thermal throttling and ensure proper heat dissipation.
4. Wiring: Route all connection cables through the designated mounting arm conduit. Protect physical connectors and secure the IP65-sealed wiring compartment carefully to preserve the unit's environmental protection rating.
5. Grounding: Connect the functional ground of the housing to the central machine grounding bus to safeguard against electromagnetic interference (EMI).
