IP2301-B400

BECKHOFF

BECKHOFF IP2301-B400 Fieldbus Box Digital I/O Module

SKU IP2301-B400

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: IP2301-B400
  • Origin Germany
  • Product Type: Fieldbus Boxes
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Fieldbus Box Fieldbus Boxes
Quantity
Call sales Contact

Product Description

Description

Designed for direct installation in demanding industrial environments without a control cabinet, the IP2301-B400 provides a robust interface between Interbus networks and decentralized field sensors or actuators. This fieldbus box features a balanced combination of four digital inputs and four digital outputs in a compact, IP67-rated housing. By routing physical signals directly at the machine level, the module significantly minimizes wiring overhead, simplifies diagnostics, and optimizes signal propagation times.

The integrated digital inputs feature a 3 ms filter time to prevent contact bounce issues, while the short-circuit-proof digital outputs deliver up to 0.5 A per channel. Standardized M8 connectors ensure secure, vibration-resistant sensor and actuator cabling, making this unit highly suitable for dynamic mechanical setups.

Features

  • Direct Interbus fieldbus connection for high-speed decentralized communication.
  • Four digital inputs (24 V DC) with an integrated 3 ms input filter.
  • Four short-circuit proof digital outputs rated at 0.5 A per channel.
  • Compact, space-saving design with robust M8 connection technology.
  • IP67 protection class allowing direct mounting on machines without protective enclosures.

Applications

  • Decentralized machine control and plant automation architectures.
  • Automotive manufacturing assembly lines utilizing Interbus fieldbus networks.
  • Material handling, packaging machinery, and conveyor line routing.
  • Industrial robotics and end-of-arm tooling control setups.

Technical Specifications

Manufacturer BECKHOFF
Part Number / Model IP2301-B400
Product Family Fieldbus Box
Protocol / Interface Interbus
Number of Inputs 4 digital inputs (24 V DC)
Input Filter Time 3 ms
Number of Outputs 4 digital outputs (24 V DC)
Max. Output Current 0.5 A per channel
Connection Method M8 screw connectors (I/O)
Nominal Supply Voltage 24 V DC
Protection Rating IP67
Operating Temperature Range 0 to +55 degC
Storage Temperature Range -25 to +85 degC
Shipping Weight 2.0 kg (approximate package weight)

Connections and Interfaces

M8 Connector Pin Input Channel Function Output Channel Function
Pin 1 +24 V DC Sensor Supply Not Connected / Free
Pin 3 0 V (GND) 0 V (GND)
Pin 4 Input Signal Output Signal (0.5 A)

Installation Guidelines

  • Mount the module directly to a flat machine frame or structure using the integrated mounting holes.
  • Ensure reliable grounding of the module case to the machinery frame to maximize electromagnetic compatibility (EMC).
  • Tighten all M8 mating connectors to the recommended torque specifications to maintain the IP67 environmental seal.
  • Route fieldbus and low-voltage control lines separate from high-noise power cables or AC motor drives to prevent signal interference.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What fieldbus protocol does the Beckhoff IP2301-B400 support?
The IP2301-B400 is designed specifically for integration with the Interbus fieldbus system.
What is the maximum current rating for the digital outputs on the IP2301-B400?
Each of the 4 digital outputs can supply a maximum current of 0.5 A at 24 V DC.
Does the IP2301-B400 require a control cabinet for installation?
No, with its IP67 protection rating, it is designed for direct machine mounting without an additional protective enclosure.
What type of connector is used for I/O wiring?
The module utilizes space-saving M8 screw connectors for both sensor inputs and actuator outputs.
