The Bently Nevada 330101-00-20-20-02-05 is a high-performance, non-contact 8 mm proximity probe designed as a core component of the 3300 XL 8 mm Proximity Transducer System. This specific variant features a fully threaded 3/8-24 UNF steel body with 0.0 inches of unthreaded length, enabling maximum depth adjustment and flexibility when threading directly into bearing housings, gearboxes, or custom mounting brackets. Unarmored by design, this model utilizes standard coaxial cabling and is optimized for installation environments where the cable is routed through protective conduit or machinery piping. With a total probe length of 2.0 meters (6.6 feet), this unit is engineered to connect to a matching 7.0-meter extension cable to form a standard 9.0-meter measurement chain, or a 3.0-meter extension cable for a 5.0-meter system, providing precise dynamic displacement data to a 3300 XL Proximitor sensor.
Unlike configuration variants that incorporate integrated plastic connector protectors (Option 01) or fluid-resistant cables (Option 11/12), this configuration employs Option 02, utilizing a standard coaxial cable terminated with a low-profile, high-integrity miniature ClickLoc coaxial connector. Additionally, Option 05 equips the probe with comprehensive international safety certifications including CSA, ATEX, and IECEx approvals for hazardous environments. This ensures safe, highly reliable operation in intrinsically safe and non-incendive machinery monitoring systems across industries such as power generation, petrochemicals, oil and gas, and water treatment.
The 330101-00-20-20-02-05 proximity probe is utilized for critical machinery vibration monitoring and protection. Common applications include:
| Option / Segment | Code on This SKU | Meaning / Configuration |
|---|---|---|
| Base Model | 330101 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, without armor |
| A: Unthreaded Length Option | 00 | 0.0 in (0 mm) unthreaded length (fully threaded) |
| B: Overall Case Length Option | 20 | 2.0 in (51 mm) overall case length |
| C: Total Length Option | 20 | 2.0 meters (6.6 feet) total length |
| D: Connector and Cable-Type Option | 02 | Miniature coaxial ClickLoc connector, standard cable (without connector protector) |
| E: Agency Approval Option | 05 | CSA, ATEX, IECEx Approvals for hazardous areas |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model / SKU | 330101-00-20-20-02-05 |
| Transducer System | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Measurement Type | Displacement, vibration, shaft position, or speed |
| Operating Principle | Eddy current non-contact measurement |
| Thread Specification | 3/8-24 UNF-2A thread, without armor |
| Nominal DC Resistance (R_PROBE) | 7.88 +/- 0.50 ohms (center conductor to outer conductor) |
| System Linear Range | 2.0 mm (80 mils) nominal |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) nominal |
| Probe Temperature Range | -51 to +177 Celsius (-60 to +350 Fahrenheit) operating |
| Sealing Material | Viton O-ring differential pressure seal between probe tip and case |
| Probe Relative Humidity | Less than 3% change in average scale factor (ASF) in 93% humidity |
| Dimensions | 45 mm x 95 mm x 95 mm (H x W x D) |
| Weight | 0.14 kg |
| Interface Type | Connector Gender | Signal / Role |
|---|---|---|
| ClickLoc Coaxial | Miniature Male Coaxial ClickLoc | RF Sensor signal connection to 3300 XL standard extension cable |
To achieve accurate calibration and long-term mechanical reliability, observe the following guidelines during installation:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-20-20-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
