The Bently Nevada 330101-00-35-10-02-00 is an unarmored 8 mm proximity probe from the 3300 XL series featuring a 3/8-24 UNF thread, a 3.5-inch fully threaded case length (0.0-inch unthreaded length), a 1.0-meter total cable length, a miniature coaxial ClickLoc connector, and a standard (non-FluidLoc) cable configuration with no agency approvals required (00 option). This specific configuration provides precise, non-contact shaft vibration and position measurement in machinery protection chains, pairing directly with a 3300 XL extension cable and a 330180 series Proximitor sensor.
Operating on the eddy-current principle, this probe measures both static shaft position (axial displacement) and dynamic shaft vibration (radial movement). The 3300 XL system delivers advanced performance and complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench-calibrate individual components. The probe's tip is molded from rugged Polyphenylene Sulfide (PPS) plastic, encapsulating the internal coil to ensure long-term stability and physical resilience inside bearing housings, gearboxes, and steam/gas turbine casings.
This high-precision proximity probe is widely used for industrial rotating machinery protection in heavy industries such as oil and gas, power generation, and petrochemicals. Typical applications include:
| Option Code | This SKU Value | Meaning |
|---|---|---|
| Orderable Part Number | 330101-00-35-10-02-00 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, without armor |
| Segment A: Unthreaded Length | 00 | 0.0 in (0 mm) unthreaded length (fully threaded) |
| Segment B: Overall Case Length | 35 | 3.5 in (89 mm) case length |
| Segment C: Total Length | 10 | 1.0 meter (3.3 feet) cable length |
| Segment D: Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| Segment E: Agency Approval | 00 | No hazardous area approvals required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number / SKU | 330101-00-35-10-02-00 |
| Product Family | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Measurement Type | Displacement (proximity) and shaft position |
| Operating Principle | Eddy current (non-contact) |
| Linear Range | 2.0 mm (80 mils), starting at approximately 0.25 mm (10 mils) from the target |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) nominal |
| Target Material | AISI 4140 steel (standard calibration) |
| Thread Size | 3/8-24 UNF-2A |
| Unthreaded Length | 0.0 in (0 mm) |
| Overall Case Length | 3.5 in (89 mm) |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector (no protector) |
| Cable Type | Standard unarmored coaxial cable |
| Operating Temperature (Probe) | -52 to +177 degC (-62 to +350 Fahrenheit) |
| Probe Pressure Rating | Designed to seal differential pressure between tip and case (Viton O-ring) |
| Frequency Response | 0 to 10 kHz, +0, -3 dB (with up to 305 meters of field wiring) |
| Dimensions | 45 mm x 95 mm x 95 mm (H x W x D) |
| Weight | 0.14 kg |
To ensure proper operation and long service life of the proximity probe, adhere to the following guidelines during installation:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-35-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
