Bently Nevada 330102-00-28-10-02-00 3300 XL 8 mm Proximity Probe with Armor

SKU 330102-00-28-10-02-00

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330102-00-28-10-02-00
Origin United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.32 kg
Dimensions: 152 mm x 152 mm x 25 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

330102-00-28-10-02-00 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF threads and flexible stainless steel armor, configured with 0.0 in unthreaded length, 2.8 in case length, 1.0 m total length, ClickLoc connector, and standard cable.

This armored configuration features a 2.8 in overall case length (Option 28) and is fully threaded (Option 00 unthreaded length). It employs a 1.0 m cable (Option 10) fitted with a miniature coaxial ClickLoc connector (Option 02) without a connector protector. Unlike variants configured with the -05 agency approval option, this model uses the -00 option, which is suitable for standard, non-hazardous areas where special industrial certifications are not required.

Features

Flexible stainless steel armor (AISI 302 or 304) with FEP outer jacket provides protection in harsh mechanical environments.
Fully threaded 3/8-24 UNF-2A case with 2.8 in total case length and 0.0 in unthreaded length.
Standard triaxial cable with 1.0 m total length for proximity transducer chains.
Miniature coaxial ClickLoc connector without protector provides standard connection to extension cables.
General application design (Option 00) for installation where hazardous area approvals are not required.

Applications

Shaft vibration and axial position measurement on industrial rotating machinery.
Asset protection monitoring in steam/gas turbines, centrifugal compressors, and generators.
Bearing clearance and oil-film thickness monitoring in non-hazardous industrial environments.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330102-00-28-10-02-00	3300 XL 8 mm proximity probe with armor, 3/8-24 UNF thread
A - Unthreaded Length Option	00	0.0 in (fully threaded)
B - Overall Case Length Option	28	2.8 in case length (71.1 mm)
C - Total Length Option	10	1.0 meter (3.3 feet)
D - Connector and Cable-Type Option	02	Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval Option	00	Agency approvals not required

Technical Specifications

Manufacturer	Bently Nevada
Part Number	330102-00-28-10-02-00
Series	3300 XL 8 mm Proximity Transducer System
Tip Diameter	8.0 mm (0.31 in)
Case Thread	3/8-24 UNF-2A
Armor Material	Flexible AISI 302 or 304 SST with FEP outer jacket
Case Material	AISI 303 or 304 stainless steel
Tip Material	Polyphenylene sulfide (PPS)
Cable Length	1.0 m (3.3 feet)
Unthreaded Length	0.0 in
Case Length	2.8 in (71.1 mm)
Connector Type	Miniature coaxial ClickLoc male
Cable Type	75 Ohm triaxial standard cable
DC Resistance (Center to Outer)	7.59 +/- 0.50 Ohms
Tensile Strength	330 N (75 lbf) maximum rated probe case to probe lead
Minimum Bend Radius	25.4 mm (1.0 in)
Operating Temperature	-52 degC to +177 degC
Weight	0.32 kg
Dimensions	152 mm x 152 mm x 25 mm (H x W x D) (coiled)

Connections and Interfaces

Connector Component	Type	Material
Probe Connector	Miniature coaxial ClickLoc (Male)	Gold-plated brass or gold-plated beryllium copper

Installation Guidelines

Do not exceed the maximum rated installation torque of 11.2 Nm (100 in-lbf) for standard forward mounted probes.
Observe the minimum permissible cable bend radius of 25.4 mm (1.0 in) during routing to prevent jacket or shield failure.
Ensure the probe tip is clear of any surrounding metal side-clamping structures to avoid calibration errors.
Tighten ClickLoc connectors finger tight to achieve a proper mechanical and electrical connection.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What configuration is specified by the 330102-00-28-10-02-00 orderable code?

This code specifies a 3300 XL 8 mm proximity probe with flexible stainless steel armor, featuring a fully threaded 3/8-24 UNF case of 2.8 inches (Option 28), 0.0 inches of unthreaded length (Option 00), 1.0 meter total cable length (Option 10), standard ClickLoc coaxial connector (Option 02), and no agency approvals (Option 00).

Does this probe model require or include a connector protector?

No, this specific configuration (Option 02) includes a standard miniature coaxial ClickLoc connector without a connector protector. Sibling configuration Option 01 is required if a connector protector is needed.

What is the function of the flexible armor on this proximity probe?

The AISI 302 or 304 stainless steel armor with FEP outer jacket provides physical protection to the FEP-insulated coaxial cable, making it suitable for environments where cable abrasion or mechanical impact may occur.

Can this probe be used in hazardous areas?

No, this configuration features Option 00 for agency approvals, meaning it is not certified for hazardous areas. If explosive atmosphere certifications are required, the -05 option should be ordered instead.
