Bently Nevada 330102-04-45-50-01-00 3300 XL 8 mm Proximity Probe

Bently Nevada 330102-04-45-50-01-00 3300 XL 8 mm Proximity Probe

Only 4 item(s) left in stock

  • Manufacturer: Bently Nevada

  • Product No.: 330102-04-45-50-01-00

  • Country of origin:United States

  • Product Type: 3300 XL 8 mm Proximity Probe

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 600g

  • Dimensions: 9.5 mm x 9.5 mm x 114.3 mm (H x W x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

View full details
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Steel probe case with 3/8-24 UNF threads featuring a 0.4 in unthreaded length (Option 04) and a 4.5 in overall case length (Option 45) — 330102-04-45-50-01-00 proximity probe.

Equipped with stainless steel armor for robust mechanical protection, this configuration includes a miniature coaxial ClickLoc connector with an integrated connector protector (Option 01). The 5.0-meter total length (Option 50) means the probe connects directly to a 5-meter 3300 XL Proximitor sensor, eliminating the need for a separate extension cable. Operating as an eddy-current system, it provides continuous shaft vibration, axial position, and speed measurements on rotating machinery.

Features

  • 3/8-24 UNF threaded steel probe case with robust stainless steel armor.
  • 0.4 in unthreaded length (Option 04) for precise clearance adjustment.
  • 4.5 in overall case length (Option 45).
  • 5.0 m total length (Option 50) designed to connect directly to a matching 5-meter Proximitor sensor.
  • ClickLoc coaxial connector featuring a fluorosilicone connector protector (Option 01) to seal out moisture.
  • Unapproved variant (Option 00) for standard non-hazardous industrial environments.

Applications

  • Steam and gas turbine shaft vibration and position monitoring.
  • Hydroelectric turbine shaft displacement tracking.
  • Boiler feed pump axial position thrust measurements.
  • Large industrial compressor and blower vibration protection.
  • Gearbox shaft dynamic motion monitoring.

Ordering Information

Option / Segment Code on This SKU Description
Orderable Part Number 330102-04-45-50-01-00 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, with armor
A - Unthreaded Length Option 04 0.4 in unthreaded length
B - Case Length Option 45 4.5 in overall case length
C - Total Length Option 50 5.0 meters (16.4 feet) total length
D - Connector and Cable-Type Option 01 Miniature coaxial ClickLoc connector with connector protector, standard cable
E - Agency Approval Option 00 Agency approval not required

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada (Baker Hughes)
Model / Part Number 330102-04-45-50-01-00
Transducer Type Non-contact eddy-current proximity probe
Probe Tip Diameter 8.0 mm (0.31 in)
Case Thread Size 3/8-24 UNF-2A
Unthreaded Length 0.4 in (10.2 mm)
Overall Case Length 4.5 in (114.3 mm)
Total Cable Length 5.0 meters (16.4 feet)
Cable Type Standard cable with stainless steel armor and FEP outer jacket
Connector Type Miniature coaxial ClickLoc
Connector Protector Included (Fluorosilicone material)
Agency Approval None (Option 00)
Operating Temperature -52 degC to +177 degC
Differential Pressure Seal Up to 70 psi (4.8 bar) across probe tip
Probe Case Material 303 Stainless Steel
Probe Tip Material Polyphenylene sulfide (PPS)
Minimum Cable Bend Radius 25.4 mm (1.0 in)
Weight 0.60 kg
Dimensions 9.5 mm x 9.5 mm x 114.3 mm (H x W x D)

Connections and Interfaces

Connector Component Connection Type / Details
Probe Connector Miniature male coaxial ClickLoc connector with gold-plated brass body
Extension Interface Connects directly to female ClickLoc connector of a 5-meter Proximitor Sensor

Installation Guidelines

  • Secure the probe housing using a 9/16 inch lock nut (supplied).
  • Verify that the unthreaded length is at least 0.8 in less than the overall case length to maintain physical housing stability.
  • Maintain a minimum cable bend radius of 25.4 mm (1.0 in) to prevent damaging the internal coaxial core and outer armor.
  • Hand-tighten ClickLoc connectors to click feedback. Do not use tools on the gold-plated connectors.
  • Run probe cables through dedicated, grounded conduits to avoid electromagnetic interference.

Compliance and Certifications

  • CE Compliant
  • RoHS Compliant
  • Manufactured under ISO 9001 certified quality standards

RECOMMENDED RELATED MODELS

Product Image Model Number / Title Condition Availability Action
330901-00-78-10-02-00 Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe Original New In Stock View Details
330104-00-04-10-11-01 Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe Original New In Stock View Details
330104-00-04-10-02-01 Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe Original New In Stock View Details
Key Features:
#Bently Nevada 3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330102-04-45-50-01-00 3300 XL 8 mm Proximity Probe

Download Open in new tab

What are the specific length and housing parameters of this 330102 probe variant?
This specific configuration (330102-04-45-50-01-00) features a 3/8-24 UNF threaded steel body with an unthreaded length of 0.4 inches (Option 04), an overall case length of 4.5 inches (Option 45), and a 5.0-meter overall cable length (Option 50).

Why does this probe require a 5-meter Proximitor sensor directly?
With a total cable length of 5.0 meters (Option 50), the probe matches the system's electrical length tuning when connected directly to a 5-meter Proximitor sensor, eliminating the need for a separate extension cable.

What is the function of the Option 01 connector type?
Option 01 designates a miniature coaxial ClickLoc connector complete with an integrated fluorosilicone connector protector, which seals the connection point against moisture and industrial contaminants.

Does the 330102-04-45-50-01-00 probe carry hazardous area certifications?
No, this specific probe is ordered with Option 00 for agency approvals, meaning it is intended for use in standard, non-hazardous industrial environments where certifications are not required.
