Bently Nevada 330103-00-04-10-02-CN 3300 XL 8 mm Proximity Probe

Only 2 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330103-00-04-10-02-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

The 330103-00-04-10-02-CN is an 8 mm proximity probe from the Bently Nevada 3300 XL transducer system series, featuring an M10 x 1 thread and an unarmored construction. This specific configuration includes a 0.0 in unthreaded length (Option 00), 0.4 in case length (Option 04), 1.0 m total system length (Option 10), and standard Miniature ClickLoc connector (Option 02), with the -CN suffix indicating a dedicated China hazardous area approval package (NEPSI/CCC). This probe is designed for use in critical rotating machinery monitoring applications, providing essential shaft vibration and axial position measurement data to the 3300 XL Proximitor sensor. The M10 x 1 metric thread ensures compatibility with standard metric mounting locations, while the unarmored design offers flexibility in applications where mechanical abrasion protection is not required. The -CN suffix ensures compliance with regional certification requirements for installations within China.

Features

M10 x 1 thread profile for metric mounting interfaces
Unarmored probe body construction for standard industrial environments
1.0 m total system length for precise signal transmission to the Proximitor sensor
Miniature ClickLoc connector for secure and reliable signal connection
China hazardous area approval package (-CN) including NEPSI and CCC certifications
Compatible with 3300 XL 8 mm transducer system components (Proximitor sensors and extension cables)

Applications

Turbine and compressor shaft vibration monitoring
Rotor axial position measurement
Critical rotating machinery protection on 8 mm probe systems
Industrial environments requiring China-specific hazardous area compliance

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330103-00-04-10-02-CN	3300 XL 8 mm Proximity Probe, M10 x 1 thread, unarmored
A - Unthreaded Length	00	0.0 in unthreaded length
B - Case Length	04	0.4 in case length
C - Total Length	10	1.0 meter (3.3 feet) system length
D - Connector/Cable	02	Miniature ClickLoc connector, standard cable
Suffix -CN	-CN	China hazardous area approval package (NEPSI/CCC)

Technical Specifications

Manufacturer	Bently Nevada
Model	330103
Product Type	3300 XL 8 mm Proximity Probe
Thread Size	M10 x 1
Armor	None (Unarmored)
Total Length	1.0 m
Connector Type	Miniature ClickLoc
Cable Type	Standard
Operating Temperature	-55 degC to +177 degC

Installation Guidelines

Ensure the probe is gapped correctly according to the 3300 XL monitoring system specifications.
Use appropriate probe lock nuts and mounting brackets to secure the probe in the machine casing.
Route cables away from high-voltage lines and sources of electromagnetic interference to maintain signal integrity.
Install with Bently Nevada approved extension cables and Proximitor sensors to maintain system calibration and certification.

Compliance and Certifications

CE marked
NEPSI (via -CN suffix)
CCC (via -CN suffix)
Compliant with standard Bently Nevada hazardous area installation drawings for nA, ec, and ia protection modes

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the -CN suffix mean on this 330103 part number?

The -CN suffix designates that the probe includes a China-specific hazardous area approval package, which includes NEPSI and CCC certifications required for installations in China.

Is this probe compatible with standard 3300 XL extension cables?

Yes, the 330103 series probe is designed to work as part of the 3300 XL 8 mm transducer system using standard 3300 XL extension cables and Proximitor sensors.

Does this probe have armor protection?

No, the 330103 model is an unarmored 8 mm probe designed for applications where mechanical abrasion protection is not required.

What is the thread size for this probe?

This probe features an M10 x 1 metric thread.
