Bently Nevada 330103-00-05-10-11-05 3300 XL 8 mm Proximity Probe

Description

The 330103-00-05-10-11-05 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread, configured for specialized mechanical integration. This non-contact, eddy-current transducer is a core component of the 3300 XL 8 mm monitoring system, designed to provide accurate shaft radial vibration and axial position measurements in critical rotating machinery. This specific configuration includes a 0.0 in unthreaded length (Option 00), 0.5 in case length (Option 05), and a 1.0 m total system length (Option 10).

The probe utilizes a miniature coaxial ClickLoc connector with an integrated connector protector and FluidLoc cable (Option 11), enhancing resistance to oil and moisture migration in harsh industrial environments. It is certified with CSA, ATEX, and IECEx approvals (Option 05) for use in hazardous locations, ensuring compatibility with rigorous safety standards in oil and gas, power generation, and petrochemical facilities.

Features

• M10 x 1 thread configuration (330103 series) for precise metric mounting.
• Option 11 FluidLoc cable and connector protector: Provides enhanced sealing against oil/fluid migration at the connector interface.
• Option 05 Agency Approval: Certified for CSA, ATEX, and IECEx hazardous area installations.
• 1.0 m total probe length (Option 10) for standard distance requirements.
• Standard 8 mm probe tip diameter for consistent gap and voltage output.
• Compatible with 3300 XL Proximitor sensors (330180) and 3300 XL extension cables.

Applications

• Radial vibration and axial position measurement on steam turbines, gas turbines, and centrifugal compressors.
• Critical machinery protection where fluid-tight sealing (FluidLoc) is required to prevent oil migration.
• Hazardous area environments requiring ATEX/IECEx/CSA compliance.
• Applications demanding M10 x 1 thread standards for probe mounting.

Ordering Information

Technical Specifications

Installation Guidelines

Ensure the probe is gapped correctly according to the machine vibration monitoring system requirements. Use the included connector protector to prevent fluid ingress at the extension cable interface. When installing in hazardous areas, ensure that all conduits and cable seals meet local explosion-proof requirements and comply with the specific certifications (CSA, ATEX, IECEx) associated with Option 05.

Compliance and Certifications

This product is certified for use in hazardous areas including CSA, ATEX, and IECEx locations. Ensure the installation adheres to the relevant Bently Nevada system manual and local safety regulations for hazardous area apparatus.
