Option 00 (0 mm unthreaded length), Option 05 (50 mm overall case length), and Option 50 (5.0 m total length) specify this fully threaded metric 3300 XL 8 mm probe configuration — 330103-00-05-50-02-05. This eddy-current proximity probe features an M10 x 1 metric thread without protective armor, utilizing a miniature coaxial ClickLoc connector (Option 02) and certified for hazardous areas under ATEX, IECEx, and CSA approvals (Option 05).
Unlike configuration variants that use standard 1.0-meter or 9.0-meter integral cables, this specific 5.0-meter cable variant must be paired directly with a 5.0-meter Proximitor sensor without the use of an extension cable, completing the 5-meter transducer loop. This standard unarmored configuration is suited for installations with pre-existing mechanical conduit where external protective armor is unnecessary.
| Option / Segment | Code on This SKU | Meaning / Description |
|---|---|---|
| Orderable Part Number | 330103-00-05-50-02-05 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, without armor |
| A - Unthreaded Length Option | 00 | 0 mm unthreaded length (fully threaded case) |
| B - Overall Case Length Option | 05 | 50 mm overall case length |
| C - Total Length Option | 50 | 5.0 meters (16.4 feet) integral cable length (must pair with 5-meter Proximitor sensor) |
| D - Connector and Cable-Type Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 05 | CSA, ATEX, and IECEx approvals for hazardous areas |
| Parameter | Value |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 330103-00-05-50-02-05 |
| Probe Tip Diameter | 8.0 mm |
| Case Thread Size | M10 x 1 (Metric) |
| Unthreaded Length | 0 mm |
| Case Length | 50 mm |
| Cable Type | Standard coaxial (unarmored) |
| Total Length | 5.0 meters (16.4 feet) |
| Connector Type | Miniature male coaxial ClickLoc |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Linear Range | 2.0 mm (80 mils) starting at 0.25 mm (10 mils) from the probe face |
| Target Material | AISI 4140 steel (calibrated target) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Cable Capacitance | 69.9 pF/m typical |
| Probe Pressure Seal | Viton O-ring differential pressure seal |
| Dimensions | 17 mm x 17 mm x 5050 mm (H x W x D) |
| Weight | 0.32 kg |
| Connector Interface | Connection Description |
|---|---|
| Miniature Coaxial Male ClickLoc Connector | Connects directly to the female coaxial connector on a 5-meter 3300 XL Proximitor sensor. No extension cable is used. |
| Certification Scheme | Details / Standard |
|---|---|
| ATEX / IECEx | Ex ia IIC T5...T1 Ga; Ex ia IIIC T90degC...T280degC Dc for EPL Ga, Gc, and Dc environments |
| CSA / cNRTLus | Class I, Division 1 & 2, Groups A, B, C, D; Class II, Groups E, F, G; Class III |
| CE | Compliant with EMC Directive 2014/30/EU and RoHS Directive 2011/65/EU |
| SIL | SIL 2 (HFT = 0), SIL 3 (HFT = 1) compatible systems |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-05-50-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 320g
Dimensions: 17 mm x 17 mm x 5050 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
