330103-00-08-05-02-CN is a 3300 XL 8 mm proximity probe featuring an M10 x 1 metric thread without armor, a 0 mm unthreaded length (Option 00), an 80 mm overall case length (Option 08), and a 0.5-meter total cable length (Option 05).
This configuration uses a standard FEP-insulated triaxial cable terminated with a miniature coaxial ClickLoc connector (Option 02). The trailing -CN suffix indicates that this device is equipped with the China hazardous area approval package, providing certified NEPSI and CCC compliance for installation in regulated Chinese environments. The probe works alongside a 3300 XL Proximitor sensor and a 3300 XL extension cable in a complete non-contact eddy-current transducer system to monitor radial shaft vibration, axial thrust position, or phase reference (Keyphasor) on industrial rotating machinery.
| Option Segment | Code on This SKU | Meaning / Description |
|---|---|---|
| Orderable Part Number | 330103-00-08-05-02-CN | 3300 XL 8 mm probe, M10 x 1 thread, without armor |
| Segment A: Unthreaded Length | 00 | 0 mm unthreaded length |
| Segment B: Overall Case Length | 08 | 80 mm overall case length |
| Segment C: Total Length | 05 | 0.5 meter (1.6 feet) total length |
| Segment D: Connector / Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| Suffix: Country Certification Package | -CN | China hazardous area approval package (NEPSI and CCC) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-08-05-02-CN |
| Transducer Type | 3300 XL 8 mm Proximity Probe |
| Thread Size | M10 x 1 metric |
| Armor Option | Without armor |
| Unthreaded Length | 0 mm |
| Overall Case Length | 80 mm |
| Total Length | 0.5 meter (1.6 feet) |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Material | Standard 75 Ohm triaxial, FEP-insulated |
| Operating Temperature | -52 degC to +177 degC |
| Sealing | Viton O-ring differential pressure seal |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Approvals | NEPSI, CCC (China hazardous area package) |
| Dimensions | 45 mm x 150 mm x 150 mm (H x W x D) |
| Weight | 0.14 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-08-05-02-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 150 mm x 150 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
