Manufacturer: Bently Nevada
Product No.: 330103-06-15-05-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
The 330103-06-15-05-02-05 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread configuration (Option 06) and a 1.5 meter total length (Option 15). This non-contact, eddy-current transducer is a core component of the 3300 XL 8 mm monitoring chain, used primarily for measuring shaft vibration and axial position on critical rotating machinery such as turbines, compressors, and pumps.
This specific configuration is supplied without armor (Option 06 base model) and utilizes a miniature coaxial ClickLoc connector (Option 02) to ensure a secure, high-integrity connection within the transducer system. It is designed for use with the 3300 XL Proximitor sensor and extension cable, providing accurate and reliable displacement measurement even in harsh industrial environments. The inclusion of Option 05 designates compliance with CSA, ATEX, and IECEx hazardous area approval requirements.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-06-15-05-02-05 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 06 | 0.6 in (per 3301 datasheet standard) |
| B - Case Length | 15 | 1.5 in (per 3301 datasheet standard) |
| C - Total Length | 05 | 0.5 meter |
| D - Connector | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-06-15-05-02-05 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Total Length | 0.5 m |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Armor | No |
| Agency Approvals | CSA, ATEX, IECEx (Option 05) |
Ensure the probe is gapped correctly according to the 3300 XL system documentation to maintain linear output. When installing in hazardous areas, ensure the complete system (probe, extension cable, and Proximitor) meets the installation requirements defined by the associated CSA, ATEX, or IECEx certifications. Secure the probe using the appropriate threaded mounting bracket and torque to manufacturer specifications to prevent loosening due to machine vibration.
