330104-00-06-05-02-00: 3300 XL 8 mm proximity probe with metric M10 x 1 threads, integrated protective armor, 0 mm unthreaded length, 60 mm overall case length, and a 0.5-meter total length. This configuration utilizes a miniature coaxial ClickLoc connector on a standard cable without a connector protector and is specified without agency approvals.
This probe operates within the 3300 XL 8 mm proximity transducer system, interfacing with a 3300 XL Proximitor sensor and a 3300 XL extension cable. It utilizes eddy-current measurement principles to measure shaft vibration, position, and speed on rotating machinery. The integrated FEP-coated stainless steel armor protects the coaxial cable from physical abrasion, mechanical impact, and chemical exposure in harsh industrial environments.
Typical heavy-industry scenarios include:
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-00-06-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 00 | 0 mm unthreaded length |
| B - Overall Case Length Option | 06 | 60 mm case length |
| C - Total Length Option | 05 | 0.5 meter (1.6 feet) |
| D - Connector and Cable-Type Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 00 | Not required / No agency approvals |
| Parameter | Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-00-06-05-02-00 |
| Product Series | 3300 XL 8 mm |
| Probe Tip Diameter | 8.0 mm |
| Thread Size | M10 x 1 |
| Thread Length (Case Length) | 60 mm |
| Unthreaded Length | 0 mm |
| Armor Material | FEP-coated stainless steel armor |
| Armor Outside Diameter | 7.67 mm (0.302 in) maximum |
| Total Length | 0.5 meters (1.6 feet) |
| Connector Type | Miniature male coaxial ClickLoc connector |
| Nominal Probe DC Resistance | 7.45 ohms +/- 0.50 ohms (center conductor to outer conductor) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 stainless steel (S30300) |
| Operating and Storage Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Sealing Material | Viton O-ring |
| Weight | 0.16 kg |
| Dimensions | 150 mm x 150 mm x 25 mm (H x W x D) |
| Connector Component | Specification / Type |
|---|---|
| Connector Type | Miniature male coaxial ClickLoc connector |
| Material | Gold-plated brass or gold-plated beryllium copper |
| Maximum Outside Diameter | 7.24 mm (0.285 in) |
| Connection Interface | Center conductor (signal) and outer conductor (shield) |
| Guideline / Limit | Requirement |
|---|---|
| Maximum Thread Engagement | 15 mm |
| Connector Tightening | Finger tight for gold 3300 XL ClickLoc connectors |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Target Material | AISI 4140 steel (standard calibration target) |
| Nominal Gap | 1.27 mm (50 mils) |
| Standard / Certification | Details |
|---|---|
| EMC Directives | 2014/30/EU (EN 61000-6-2, EN 61000-6-4) |
| RoHS Directives | 2011/65/EU; China RoHS EFUP 15 years (SJ/T 11364-2024) |
| Functional Safety | SIL 2 capable (HFT=0), SIL 3 capable (HFT=1) when used within a complete certified system |
| Agency Approvals (Option 00) | None required for standard non-hazardous industrial areas |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-00-06-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 160g
Dimensions: 150 mm x 150 mm x 25 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
