330104-01-14-05-01-CN specifies this 3300 XL 8 mm metric threaded proximity probe with flexible stainless steel armor, featuring an M10 x 1 thread, a 10 mm unthreaded length (Option 01), a 140 mm overall case length (Option 14), and a 0.5-meter total length (Option 05) with a ClickLoc connector and connector protector (Option 01).
This specific configuration includes the trailing suffix -CN, which designates the China hazardous area approval package. This option certifies the transducer system for use in hazardous environments under NEPSI and CCC regulations, replacing standard agency approvals for Chinese compliance.
This armored metric proximity probe is deployed in demanding industrial environments where rotating machinery protection is critical. Typical use cases include:
| Option Segment | Code Value | Meaning / Description |
|---|---|---|
| Orderable Part Number | 330104-01-14-05-01-CN | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor |
| Option A - Unthreaded Length | 01 | 10 mm unthreaded length |
| Option B - Overall Case Length | 14 | 140 mm case length |
| Option C - Total Length | 05 | 0.5 meter (1.6 feet) total length |
| Option D - Connector / Cable | 01 | Miniature ClickLoc coaxial connector with connector protector, standard cable |
| Suffix -CN | -CN | China hazardous area approval package (NEPSI and CCC) |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-01-14-05-01-CN |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Case Thread Size | M10 x 1 |
| Armor Material | Flexible stainless steel armor sleeve |
| Unthreaded Length | 10 mm |
| Overall Case Length | 140 mm |
| Total Length | 0.5 meter (1.6 feet) |
| Connector Type | Miniature coaxial ClickLoc |
| Linear Range | 2.0 mm (80 mils), from approximately 0.25 mm (10 mils) to 2.25 mm (90 mils) gap |
| System Scale Factor | 7.87 V/mm (200 mV/mil) typical when paired with 3300 XL extension cable and Proximitor |
| Operating Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) |
| Pressure Limit | Seals differential pressure up to 7.0 bar (100 psi) |
| Weight | 150 g |
| Dimensions | 160 mm x 160 mm x 45 mm (H x W x D) |
Ensure correct system operation by adhering to professional machinery protection installation standards:
| Certification Authority | Marking / Protection Type |
|---|---|
| NEPSI (China) | Ex ia IIC T4/T5 Ga, Ex nA IIC T4/T5 Gc, Ex ec IIC T4/T5 Gc |
| CCC (China) | Compulsory Certification for explosion-proof electrical equipment |
| RoHS | Compliant with applicable restrictions |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-01-14-05-01-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 150g
Dimensions: 160 mm x 160 mm x 45 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
330104-01-14-05-01-CN specifies this 3300 XL 8 mm metric threaded proximity probe with flexible stainless steel armor, featuring an M10 x 1 thread, a 10 mm unthreaded length (Option 01), a 140 mm overall case length (Option 14), and a 0.5-meter total length (Option 05) with a ClickLoc connector and connector protector (Option 01).
This specific configuration includes the trailing suffix -CN, which designates the China hazardous area approval package. This option certifies the transducer system for use in hazardous environments under NEPSI and CCC regulations, replacing standard agency approvals for Chinese compliance.
This armored metric proximity probe is deployed in demanding industrial environments where rotating machinery protection is critical. Typical use cases include:
| Option Segment | Code Value | Meaning / Description |
|---|---|---|
| Orderable Part Number | 330104-01-14-05-01-CN | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor |
| Option A - Unthreaded Length | 01 | 10 mm unthreaded length |
| Option B - Overall Case Length | 14 | 140 mm case length |
| Option C - Total Length | 05 | 0.5 meter (1.6 feet) total length |
| Option D - Connector / Cable | 01 | Miniature ClickLoc coaxial connector with connector protector, standard cable |
| Suffix -CN | -CN | China hazardous area approval package (NEPSI and CCC) |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-01-14-05-01-CN |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Case Thread Size | M10 x 1 |
| Armor Material | Flexible stainless steel armor sleeve |
| Unthreaded Length | 10 mm |
| Overall Case Length | 140 mm |
| Total Length | 0.5 meter (1.6 feet) |
| Connector Type | Miniature coaxial ClickLoc |
| Linear Range | 2.0 mm (80 mils), from approximately 0.25 mm (10 mils) to 2.25 mm (90 mils) gap |
| System Scale Factor | 7.87 V/mm (200 mV/mil) typical when paired with 3300 XL extension cable and Proximitor |
| Operating Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) |
| Pressure Limit | Seals differential pressure up to 7.0 bar (100 psi) |
| Weight | 150 g |
| Dimensions | 160 mm x 160 mm x 45 mm (H x W x D) |
Ensure correct system operation by adhering to professional machinery protection installation standards:
| Certification Authority | Marking / Protection Type |
|---|---|
| NEPSI (China) | Ex ia IIC T4/T5 Ga, Ex nA IIC T4/T5 Gc, Ex ec IIC T4/T5 Gc |
| CCC (China) | Compulsory Certification for explosion-proof electrical equipment |
| RoHS | Compliant with applicable restrictions |
