Bently Nevada 330104-01-17-05-01-05 3300 XL 8 mm Proximity Probe

Description

The 330104-01-17-05-01-05 is a 3300 XL 8 mm Proximity Probe configured with a 0.1 in unthreaded length (Option 01), a 1.7 in case length (Option 17), and a 0.5 m total cable length (Option 05). This probe features a robust M10 x 1 threaded body with integrated protective stainless steel armor to withstand harsh industrial environments, ensuring reliable mechanical protection for the probe lead.

This transducer is designed for non-contact eddy-current displacement measurement, serving as a primary component in 3300 XL monitoring chains. It includes a miniature coaxial ClickLoc connector with a connector protector (Option 01) and carries CSA, ATEX, and IECEx agency approvals (Option 05) for use in hazardous areas. It pairs with the 3300 XL Proximitor sensor and extension cable to provide continuous monitoring of shaft vibration and axial position in critical rotating machinery.

Features

• M10 x 1 threaded probe body with integrated stainless steel armor for improved lead protection.
• Option 01 (0.1 in unthreaded length) and Option 17 (1.7 in case length) for precise installation depth.
• 0.5 m total system length (Option 05) optimized for short-range monitoring applications.
• Miniature coaxial ClickLoc connector with connector protector (Option 01) ensures a secure, reliable connection.
• Certified for hazardous area installations with CSA, ATEX, and IECEx approvals (Option 05).
• Electrically and physically interchangeable with 3300-series 5 mm and 8 mm components.

Applications

• Turbine and compressor shaft vibration monitoring.
• Axial rotor position measurement.
• Hazardous area machinery protection (oil and gas, petrochemical).
• Critical rotating machinery vibration analysis.

Ordering Information

Technical Specifications

Installation Guidelines

• Ensure the probe gap is set according to the technical documentation for the specific machinery application.
• When using armored probes, ensure the armor is properly secured to prevent abrasion against machine surfaces.
• Use the provided connector protector to prevent ingress of oil or moisture into the coaxial connection.
• For hazardous area applications, ensure installation complies with the requirements specified in the CSA, ATEX, or IECEx certification documentation.
• Maintain a minimum bend radius for the coaxial cable to prevent signal degradation or internal conductor damage.

Compliance and Certifications

• CSA: Certified for use in hazardous areas.
• ATEX: Compliant for use in explosive atmospheres.
• IECEx: Certified for international hazardous area use.
