330104-02-13-10-01-00: 3300 XL 8 mm proximity probe with metric M10 x 1 threads, integrated stainless steel protective armor, 20 mm unthreaded length (Option 02), 130 mm overall case length (Option 13), 1.0-meter total length (Option 10), miniature coaxial ClickLoc connector with connector protector (Option 01), and no agency approvals required (Option 00).
This specific metric thread configuration is equipped with flexible stainless steel armor to shield the coaxial cable against abrasion, mechanical impact, and harsh industrial environments, unlike unarmored variants like the 330103. The inclusion of a ClickLoc connector protector (Option 01) protects the termination from moisture ingress and physical stress when paired with standard 3300 XL extension cables. With a total system length of 1.0 meter, this probe functions as part of a complete 3300 XL 8 mm eddy-current transducer system, matching standard Proximitor sensors.
| Option Category | Code Value | Configuration Meaning |
|---|---|---|
| Orderable Part Number | 330104-02-13-10-01-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 metric thread, armored, 20 mm unthreaded, 130 mm case, 1.0 m total length, with connector protector, no approvals |
| A - Unthreaded Length Option | 02 | 20 mm unthreaded length |
| B - Overall Case Length Option | 13 | 130 mm overall case length |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable-Type Option | 01 | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| E - Agency Approval Option | 00 | No agency approvals required |
| Parameter | Value / Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / SKU | 330104-02-13-10-01-00 |
| Product Series | 3300 XL 8 mm Proximity Transducer System |
| Thread Size | M10 x 1 |
| Armor Protection | Flexible AISI 302/304 stainless steel sleeve with FEP outer jacket |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Operating and Storage Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Nominal DC Resistance | 7.59 ohms +/- 0.50 ohms (center conductor to outer conductor at 1.0 m length) |
| Maximum Case Torque | 22.6 N-m (200 in-lbf) maximum rated; 7.5 N-m (66 in-lbf) recommended |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Maximum Thread Engagement | 15 mm |
| Tensile Strength (Maximum Rated) | 330 N (75 lbf) probe case to probe lead |
| Coiled Shipping Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) |
| Weight | 0.22 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-02-13-10-01-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 220g
Dimensions: 150 mm x 150 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
