Manufacturer: Bently Nevada
Product No.: 330104-05-13-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
330104-05-13-10-02-00: 3300 XL 8 mm reverse mount proximity probe, M10 x 1 thread, with armored cable. This configuration features a 50 mm unthreaded length (Option 05) and a 130 mm case length (Option 13). The assembly provides a 1.0 m total system length (Option 10) utilizing a standard miniature coaxial ClickLoc connector (Option 02), with no agency approvals required (Option 00).
The 3300 XL 8 mm transducer system is used for non-contact shaft vibration and axial position measurements in critical rotating machinery. Designed for integration into 3300 XL monitoring chains, this probe pairs with the 3300 XL Proximitor sensor and extension cable to deliver accurate, linear displacement signals across various industrial applications, including turbines, compressors, and high-speed pumps. The inclusion of an armored cable provides additional mechanical protection for the lead wire against abrasion or environmental wear.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330104-05-13-10-02-00 | 3300 XL 8 mm Reverse Mount Proximity Probe |
| A - Unthreaded Length | 05 | 50 mm (5.0 cm) |
| B - Case Length | 13 | 130 mm (13.0 cm) |
| C - Total Length | 10 | 1.0 meter (3.3 feet) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-05-13-10-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Mounting Type | Reverse Mount |
| Cable Type | Armored, Coaxial |
| Total Length | 1.0 m |
| Connector | Miniature coaxial ClickLoc |
| Temperature Range | -51 degC to +177 degC |
| Material | AISI 303 Stainless Steel (Probe tip: Polyphenylene sulfide) |
The 330104 reverse mount probe is installed by threading it into the bearing housing or machinery case from the interior. Ensure the probe tip is positioned at the recommended gap distance from the target (typically 1.27 mm nominal). Utilize the included lock nuts for securing the probe position. Route the armored cable away from high-vibration paths and potential pinch points. Keep the coaxial connector clean and free of moisture during installation to maintain signal integrity.
