Bently Nevada 330106-05-30-05-02-00 3300 XL 8 mm Reverse Mount Probe

Only 4 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330106-05-30-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Reverse Mount Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

The 330106-05-30-05-02-00 is a 3300 XL 8 mm reverse mount proximity probe, featuring an M10 x 1 thread and a configured unthreaded length of 05 (50 mm), a case length of 30 (300 mm), and a 0.5 meter total system length. This probe is part of the Bently Nevada 3300 XL 8 mm Proximity Transducer System, specifically designed for applications where the probe must be mounted inside the machine case. This configuration includes a standard Miniature ClickLoc coaxial connector (Option 02) and requires no specific agency approvals (Option 00). As a reverse mount probe, it is used in monitoring chains for shaft vibration and axial position on critical rotating machinery, such as turbines and compressors, providing reliable, non-contact eddy-current displacement measurement when paired with compatible 3300 XL Proximitor sensors and extension cables.

Features

M10 x 1 thread reverse mount design for internal machinery installation
Option 05 (50 mm) unthreaded length
Option 30 (300 mm) overall case length
Option 05 (0.5 meter) total system length
Option 02 connector type: Miniature ClickLoc coaxial connector, standard cable
Option 00 agency approval: Not required
Compatible with 3300 XL 8 mm monitoring chains and Proximitor sensors

Applications

Turbine shaft vibration monitoring
Compressor rotor position measurement
Critical rotating machinery protection
Fluid film bearing monitoring where reverse-mount configuration is required

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330106-05-30-05-02-00	3300 XL 8 mm Reverse Mount Probe, M10 x 1 thread
A - Unthreaded Length	05	50 mm (per datasheet configuration)
B - Overall Case Length	30	300 mm (per datasheet configuration)
C - Total Length	05	0.5 meter (1.6 feet)
D - Connector	02	Miniature ClickLoc coaxial connector, standard cable
E - Agency Approval	00	Not required

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330106-05-30-05-02-00
Probe Diameter	8.0 mm
Thread Size	M10 x 1
Mounting Type	Reverse Mount
Total Length	0.5 meter
Connector	Miniature ClickLoc
Cable Type	Standard
Agency Approvals	Not required

Installation Guidelines

Ensure the probe is gapped according to the specific 3300 XL system manual instructions to maintain linear output.
Reverse mount probes are designed for installation through a mounting bracket or machine casing; ensure the correct thread engagement and torque values.
Route coaxial cables away from high-voltage lines or sources of electromagnetic interference to prevent signal noise.
The Miniature ClickLoc connector should be kept clean and dry; verify proper connection seating to ensure signal integrity.

Compliance and Certifications

This unit is designated for standard applications where specific hazardous area approvals (CSA, ATEX, IECEx) are not required (Option 00).

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Reverse Mount Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the 330106 model number represent in the Bently Nevada catalog?

The 330106 is a 3300 XL 8 mm proximity probe designed specifically for reverse mount applications using M10 x 1 threads.

What is the significance of the Option 02 connector code in this SKU?

Option 02 specifies that the probe is equipped with a standard Miniature ClickLoc coaxial connector without a connector protector.

Is this probe suitable for hazardous area installations?

No, the 330106-05-30-05-02-00 SKU uses Option 00 for Agency Approval, meaning it does not carry hazardous area certifications like CSA, ATEX, or IECEx.

Can I use this probe with a 5-meter Proximitor sensor?

The 0.5 meter length (Option 05) is standard; however, always ensure the total system length (probe + extension cable) matches the requirements of your specific 3300 XL Proximitor sensor.
