Manufacturer: Bently Nevada
Product No.: 330130-080-02-05
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
The 330130-080-02-05 is an 8.0 meter (26.2 foot) standard extension cable for 3300 XL 8 mm proximity transducer systems. This cable serves as the critical interconnect between the proximity probe and the Proximitor sensor, maintaining signal integrity in machinery vibration monitoring applications. This specific configuration features Option 02, providing a standard cable with an integrated connector protector, and Option 05, signifying compliance with CSA, ATEX, and IECEx hazardous area approvals.
This extension cable is engineered for use in 3300 XL transducer systems where the total system length (probe + extension cable) must match the calibration of the Proximitor sensor. The ClickLoc connector design ensures consistent electrical connection and mechanical robustness in industrial environments. Proper installation and use of the connector protector (included in this configuration) are required to maintain environmental sealing and protection of the coaxial connection points.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330130-080-02-05 | 3300 XL Standard Extension Cable |
| A - Cable Length | 080 | 8.0 meters (26.2 feet) |
| B - Cable Option | 02 | Standard cable with connector protector |
| C - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 330130 |
| Cable Length | 8.0 meters |
| Cable Type | Standard coaxial cable |
| Connector Type | ClickLoc miniature coaxial |
| Approvals | CSA, ATEX, IECEx (Option 05) |
| Temperature Range | -51 degC to +177 degC |
Ensure the total length of the probe and extension cable matches the requirements of the Proximitor sensor (e.g., 5-meter or 9-meter systems). Apply the provided connector protectors to all probe-to-cable and cable-to-Proximitor connections to prevent moisture and debris ingress. Avoid sharp bends in the cable; follow standard minimum bend radius guidelines for coaxial instrumentation cabling. Ensure the cable is properly secured to minimize movement and potential abrasion during machinery operation.
