Bently Nevada 330730-080-00-05 3300 XL 11 mm Extension Cable

Bently Nevada 330730-080-00-05 3300 XL 11 mm Extension Cable

Only 7 item(s) left in stock

  • Manufacturer: Bently Nevada

  • Product No.: 330730-080-00-05

  • Country of origin:United States

  • Product Type: 3300 XL 11 mm Extension Cable

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 180g

  • Dimensions: 50 mm x 100 mm x 100 mm (H x W x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

View full details
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

330730-080-00-05 specifies this 3300 XL 11 mm extension cable configuration, featuring an 8.0-meter cable length, standard unarmored coaxial construction, and multiple hazardous area agency approvals. This cable serves as a link within the non-contact eddy-current transducer system, connecting the proximity probe to the Proximitor sensor.

Unlike variants that incorporate stainless steel armor or connector protectors, this standard triaxial cable configuration maintains a compact outer diameter of 3.7 mm, maximizing flexibility during installation inside conduits. It operates under challenging conditions, withstanding temperatures from -52 degC to +177 degC while preserving low electrical loss and consistent capacitive properties required for vibration and position monitoring.

Features

  • Cable Length: 8.0 meters (26.2 feet) of triaxial cable matching standard system requirements.
  • Cable Type: Standard unarmored triaxial cable featuring chemical-resistant fluoroethylene propylene (FEP) insulation.
  • Connector Design: Miniature coaxial ClickLoc connectors at each end for standard, tool-free coupling.
  • Agency Approvals: Multiple hazardous area certifications under Option 05, including CSA, ATEX, and IECEx.
  • Routing Flexibility: 25.4 mm minimum bend radius allows installation within restricted machinery spaces.

Applications

This extension cable is used in 3300 XL 11 mm proximity transducer systems on rotating machinery, including:

  • Steam and gas turbine shaft vibration and axial position monitoring.
  • Centrifugal and reciprocating compressor rotor position sensing.
  • Rotating machinery protection in oil, gas, chemical, and power generation facilities.

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330730-080-00-05 3300 XL 11 mm Extension Cable
A - Cable Length 080 8.0 meters (26.2 feet)
B - Connector and Cable 00 Standard cable (unarmored, no connector protector)
C - Agency Approval 05 Multiple Approvals (CSA, ATEX, IECEx, and others)

Technical Specifications

Parameter Value
Manufacturer Bently Nevada
Part Number / SKU 330730-080-00-05
Transducer System 3300 XL 11 mm Proximity Transducer System
Cable Length 8.0 meters (26.2 feet)
Cable Construction 75 ohm triaxial, FEP insulated, unarmored
Cable Outer Diameter 3.7 mm maximum
Connector Type Miniature coaxial ClickLoc connectors (male and female)
Connector Material Gold-plated brass
Center Conductor Resistance (RCORE) 0.6 +/- 0.2 ohms
Coaxial Conductor Resistance (RJACKET) 2.0 +/- 0.5 ohms
Extension Cable Capacitance 69.9 pF/m (21.3 pF/ft) typical
Minimum Bend Radius 25.4 mm (1.0 in)
Tensile Strength (Maximum Rated) 270 N (60 lb) from probe lead to extension cable connectors
Operating and Storage Temperature -52 degC to +177 degC (-62 degF to +351 degF)
System Compatibility 3300 XL 11 mm Proximity Probe (1.0 m length) and 3300 XL 11 mm Proximitor Sensor

Installation Guidelines

  • Bend Radius Control: Route the cable to ensure no bend is tighter than the 25.4 mm (1.0 inch) minimum limit, protecting the internal coaxial structure.
  • Connection Security: Connect ClickLoc coaxial joints hand-tight. Do not apply tools that could exceed the maximum torque limit of 0.565 N-m (5 in-lb).
  • Moisture Mitigation: Ensure connections are protected from oil and moisture. Avoid silicone tape in environments where probe-to-extension cable joints are exposed to turbine oil.
  • System Matching: This 8.0-meter cable must be matched with a 1.0-meter probe to align with a 9.0-meter Proximitor Sensor calibration.

Compliance and Certifications

Certification Type Standard or Rating
Hazardous Area Classifications Multiple approvals (CSA, ATEX, IECEx) for intrinsically safe (ia) and non-incendive (nA, ec) installations
EMC Directives EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions)
RoHS Directives European Directive 2011/65/EU; China RoHS (15-year EFUP)
Functional Safety SIL 2 (HFT = 0), SIL 3 (HFT = 1) compliant
Maritime Certifications ABS Rules for Conditions of Classification
Loading product navigation…

RECOMMENDED RELATED MODELS

Product Image Model Number / Title Condition Availability Action
330901-00-78-10-02-00 Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe Original New In Stock View Details
330104-00-04-10-11-01 Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe Original New In Stock View Details
330104-00-04-10-02-01 Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe Original New In Stock View Details
Key Features:
#Bently Nevada 3300 XL #Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330730-080-00-05 3300 XL 11 mm Extension Cable

Download Open in new tab

What does the 080 segment signify on this Bently Nevada cable?
The 080 segment indicates a cable length of 8.0 meters (26.2 feet).

Does the 330730-080-00-05 cable include armor protection?
No, the 00 option code specifies a standard unarmored coaxial cable with standard FEP insulation and no connector protector.

Which approvals does the multiple approval option include?
The 05 option provides multiple hazardous area agency approvals, including certifications from CSA, ATEX, and IECEx for intrinsic safety and non-incendive environments.

What is the recommended installation bend radius for this coaxial cable?
The minimum recommended bend radius is 25.4 mm (1.0 inch) to preserve coaxial integrity and maintain consistent system calibration.
