Bently Nevada 330730-080-03-00 3300 XL 11 mm Extension Cable

SKU 330730-080-03-00

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330730-080-03-00
Country of origin:United States
Product Type: 3300 XL 11 mm Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 180g
Dimensions: 50 mm x 100 mm x 100 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

Option 080 (8.0 m length) and Option 03 (armored cable with connector protector) define the configuration of this 3300 XL 11 mm Extension Cable, orderable as 330730-080-03-00.

Constructed with flexible AISI 302 stainless steel armor and an outer FEP jacket, the cable provides mechanical shielding against physical abrasion and environmental exposure. It operates as part of a 9.0 meter total system length setup when connected to a 1.0 meter 3300 XL 11 mm probe and a 3300 XL 11 mm Proximitor sensor, facilitating shaft vibration and axial position measurement on rotating machinery.

Features

8.0-meter (26.2 feet) extension cable length (Option 080) for 9.0-meter system configuration.
Flexible AISI 302 stainless steel armor with FEP outer jacket (Option 03) prevents mechanical damage.
Integrated coaxial ClickLoc connector protector seals and locks the probe-to-cable joint.
Gold-plated brass connectors ensure low electrical resistance.
Extended operating temperature range of -52 degC to +177 degC (-62 degF to +351 degF).
Standard low electrical capacitance of 69.9 pF/m preserves signal transmission quality.

Applications

Shaft vibration monitoring on critical rotating machinery
Rotor axial position measurement
Industrial gas and steam turbine monitoring
Centrifugal and axial compressor protection systems
Gearbox and pump vibration analysis

Ordering Information

Option Segment	Code on This SKU	Meaning / Description
Orderable Part Number	330730-080-03-00	3300 XL 11 mm Extension Cable, armored with connector protector, 8.0 meters
A - Cable Length	080	8.0 meters (26.2 feet)
B - Connector and Cable	03	Armored cable with connector protector
C - Agency Approval	00	Not required

Technical Specifications

Manufacturer	Bently Nevada
Part Number / Model	330730-080-03-00
Product Series	3300 XL 11 mm Transducer System
Cable Material	75 Ohm triaxial, fluoroethylene propylene (FEP) insulated
Armor Material	Flexible AISI 302 stainless steel with outer FEP jacket
Connector Material	Gold-plated brass ClickLoc coaxial connectors
Connector-to-Connector Torque	Finger tight (recommended), 0.565 N-m (5 in-lb) maximum
Minimum Cable Bend Radius	25.4 mm (1.0 in)
Tensile Strength (Maximum)	270 N (60 lb) at probe-to-extension cable connection
Cable DC Resistance (Center)	0.6 +/- 0.2 ohms
Cable DC Resistance (Coaxial)	2.0 +/- 0.5 ohms
Extension Cable Capacitance	69.9 pF/m (21.3 pF/ft) typical
Operating and Storage Temperature	-52 degC to +177 degC (-62 degF to +351 degF)
Total System Compatibility	9.0 meters (when paired with 1.0 m probe)

Installation Guidelines

Maintain a minimum bend radius of 25.4 mm (1.0 in) along the entire cable run to avoid coaxial signal degradation.
Ensure connections are hand-tightened before applying a maximum torque limit of 0.565 N-m.
Utilize the integrated connector protector to protect against moisture, turbine oil, and other aggressive contaminants.
Confirm that the total length of the extension cable combined with the probe matches the system length requirement of the Proximitor sensor (9.0 meters).
Avoid routing coaxial cables alongside high-power alternating current (AC) cables to eliminate electrical noise risk.

Compliance and Certifications

European Union EMC Directive 2014/30/EU
EN 61000-6-2 (Electromagnetic Immunity for Industrial Environments)
EN 61000-6-4 (Electromagnetic Emissions for Industrial Environments)
RoHS Directive 2011/65/EU and China RoHS

FAQ

What is the cable length of the 330730-080-03-00 extension cable?

This specific configuration features an 8.0-meter (26.2 feet) cable length, which when combined with a 1.0-meter 11 mm probe completes a 9.0-meter total transducer system.

What physical protection does Option 03 provide on this extension cable?

Option 03 specifies flexible AISI 302 stainless steel armor with an outer FEP jacket to prevent mechanical wear, plus an integrated connector protector that seals and locks the connection.

Can I use this extension cable in hazardous areas?

The 330730-080-03-00 has Option 00 for agency approvals, meaning no specific hazardous area certifications are provided. For certified locations, select Option 05.
