Bently Nevada 330905-00-13-05-02-05 3300 XL NSv Proximity Probe

Only 5 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330905-00-13-05-02-05
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

The 330905-00-13-05-02-05 is a 3300 XL NSv proximity probe configuration featuring an M10x1 thread, 0.0 mm unthreaded length (Option 00), 1.3 in case length (Option 13), and 0.5 m total probe length (Option 05). This unit is equipped with a standard miniature coaxial ClickLoc connector without a connector protector (Option 02) and is certified with multiple hazardous area approvals (Option 05).

Designed for use within the 3300 XL NSv Proximity Transducer System, this probe is engineered for non-contact displacement measurement in tight clearance applications, such as small-bore machinery or aeroderivative turbines where standard-sized probes may not fit. The NSv (Near-surface) design maintains linear performance in reduced target geometries. It must be paired with a compatible 3300 XL NSv Proximitor Sensor (330980) and extension cable (330930) to form a complete monitoring loop for shaft vibration and axial position.

Features

M10x1 probe thread (330905 base model)
Option 00: 0.0 mm unthreaded length configuration
Option 13: 1.3 in case length
Option 05: 0.5 m total probe length
Option 02: Miniature coaxial ClickLoc connector, standard cable (no connector protector)
Option 05: Multiple hazardous area approvals (CSA, ATEX, IECEx)
Polyphenylene sulfide (PPS) probe tip with AISI 304 stainless steel case
Compatible with 3300 XL NSv Proximitor Sensor and extension cable

Applications

Small-bore machinery monitoring
Aeroderivative turbines
High-speed rotating equipment with limited target area
Shaft vibration and axial position measurement
Critical machinery protection in hazardous environments

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330905-00-13-05-02-05	3300 XL NSv Proximity Probe, M10x1
A - Unthreaded Length	00	0.0 mm
B - Case Length	13	1.3 in
C - Total Length	05	0.5 m
D - Connector/Cable	02	Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval	05	Multiple approvals (CSA, ATEX, IECEx)

Technical Specifications

Manufacturer	Bently Nevada
Part Number	330905-00-13-05-02-05
Probe Diameter	M10x1
Total Length	0.5 m
Connector Type	Miniature coaxial ClickLoc
Case Material	AISI 304 stainless steel
Tip Material	Polyphenylene sulfide (PPS)
Agency Approvals	CSA, ATEX, IECEx

Compliance and Certifications

CSA (Class I, Division 2; Class I, Zone 0/2)
ATEX / IECEx (Ex ia IIC; Ex nA / ec IIC)
RoHS compliant
Functional Safety: SIL 2 (HFT=0) / SIL 3 (HFT=1)

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 NSv #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What is the primary difference between the 330905 probe and other 3300 NSv probes?

The 330905 model is specifically the M10x1 threaded probe without armor. Other models in the series differ by thread size (1/4-28 UNF, 3/8-24 UNF, M8x1) or the presence of integral stainless steel armor.

What does the Option 05 for Agency Approval signify on this SKU?

Option 05 indicates that the probe is certified for multiple hazardous area environments, including CSA, ATEX, and IECEx approvals, when installed according to the appropriate Bently Nevada drawings.

Does this probe require a connector protector?

This specific configuration (Option 02) includes a standard miniature coaxial ClickLoc connector without a connector protector. If you require protection, you can order the 3300 NSv Connector Kit as an accessory.

Is this probe compatible with standard 3300 XL Proximitor sensors?

No, this probe is part of the 3300 XL NSv system and must be used with the 330980 NSv Proximitor Sensor and compatible NSv extension cables to ensure correct system performance and scale factor.
