Emerson DeltaV VE3008 KJ2005X1-MQ1 12P6381X032 MQ Controller

Only 3 item(s) left in stock

Manufacturer: Emerson
Product No.: VE3008 KJ2005X1-MQ1 12P6381X032
Country of origin:United States
Product Type: Controller Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1200g
Dimensions: 4.1cm x 15.9cm x 10.8cm
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

The Emerson VE3008 is an MQ Controller designed for the DeltaV Distributed Control System (DCS). This hardware component provides communication and control between field devices and other nodes on the control network. It executes local control strategies with execution speeds up to every 100 ms. The VE3008 offers identical configurable memory and execution capabilities to the legacy MD Plus Controller, supporting seamless system scalability and legacy migrations. Online operational updates are automatically captured to ensure data integrity within the plant architecture.

Features

Seamlessly executes control strategies with configurable update loops as fast as 100 ms.
Retains entire active control strategies within internal non-volatile random-access memory (NVM RAM) to enable completely autonomous cold restarts following a supply power loss.
Integrates full-duplex Ethernet communication ports capable of reaching up to 100 MB/s maximum throughput.
Performs automated system identification and network addressing immediately upon initial system power-up.
Detects physical subsystem I/O interfaces automatically to identify distinct connected channel attributes.
Built-in visual identification function allows operators to flash specific faceplate LEDs via user interface software commands.
Facilitates data pass-through capabilities to securely route smart HART device variables directly to engineering workstations.
Provides functional compatibility for assignments to CHARM I/O Cards (CIOC) for electronic marshalling schemes when operating on supported software environments.

Applications

Chemical processing facilities and distillation column control networks.
Power generation utility oversight and distributed node monitoring.
Continuous batch execution and process loop regulations in oil and gas refineries.
Legacy automation platform migrations including PROVOX and RS3 structures.

Ordering Information

Description	Model Number
MQ Controller	VE3008
Controller Module Hold-down Screw; box of 20	KJ4010X1-BP3

Technical Specifications

Parameter	Specification
Manufacturer	Emerson
Model Type	MQ Controller
Hardware Assembly / Part Number	KJ2005X1-MQ1
Component Layout Print Reference	12P6381X022 REV B
Manufacturing Origin	Made in Malaysia
User Memory Capacity	48 MB
Device Signal Tag (DST) Range	50 to 750 DSTs
Power Supply Source Requirement	Supplied by System Power Supply through 2-wide Power/Controller Carrier
Power Dissipation	5.0 W typical, 7.0 W maximum
Internal Overcurrent Protection	3.0 A, non-replaceable fuses
Primary Network Interface	8-pin RJ-45 connector
Redundant Network Interface	8-pin RJ-45 connector
Module Width	4.18 cm (1.65 in.)
Module Depth	13.91 cm (5.48 in.)
Module Height	16.06 cm (6.32 in.)
Operating Temperature Limit	-40 to 70 degC (-40 to 158 degF)
Storage Temperature Limit	-40 to 85 degC (-40 to 185 degF)
Relative Humidity Bounds	5 to 95%, non-condensing
Environmental Gaseous Protection	ISA-S71.04-1985 Airborne Contaminants Class G3 Conformal coating
Operational Shock Resistance	10 g 2-sine wave for 11 ms
Operational Vibration Limit	1 mm peak-to-peak from 5 Hz to 16 Hz; 0.5 g from 16 Hz to 150 Hz

Connections/Interfaces

LED Indicator Status	Functional Meaning
Green - Power	Indicates DC power is applied
Red - Error	Indicates an error condition
Green - Active	Indicates that the controller is operating as the primary controller
Green - Standby	Indicates that the controller is operating as a backup controller (reserved for future use)
Yellow Flashing - Pri. CN	Indicates valid primary control network communication
Yellow Flashing - Sec. CN	Indicates valid secondary control network communication
All except Power flashing	Visual identification of controller initiated from user interface software by ping command
All except Power flashing, alternating	Firmware upgrade in progress

Installation Guidelines

Carrier Mounting: The module must be positioned and installed securely on the right slot of a compatible M-series Power/Controller Carrier.
Power Provision: Each controller node demands an independent, dedicated system power supply unit tied to the carrier backplane.
Software Version Dependencies: Baseline operation requires DeltaV software version v10.3.1 or higher. Electronic marshalling or CHARM structural allocation necessitates software version v14.3 or later.
Network Isolation: For implementations utilizing Electronic Marshalling, dedicated DeltaV Smart Switches must be installed to bridge data paths between controllers and CHARM I/O Cards (CIOC).

Compliance and Certifications

CE Compliance: Certified
EMC Standards: EN 61326-1
FM Certification (USA): Class I, Division 2, Groups A, B, C, D, T4 hazardous locations
cFM Certification (Canada): Class I, Division 2, Groups A, B, C, D, T4 hazardous locations
ATEX Classification: II 3G Ex ec IIC T4 Gc (Zone 2 installation environments)
IEC Ex Classification: II 3G Ex ec IIC T4 Gc
Marine Appraisals: Compliant with IACS E10 guidelines; holds ABS Certificate of Design Assessment and DNV Type Approval Certificate
Industrial Cybersecurity: Certified to Achilles Communications Certification Level 2 requirements

Key Features:

#Controller Modules #DeltaV

What software version is required to use the module?

The device requires a baseline of DeltaV system software version v10.3.1 or later. If you need to assign CHARMs for electronic marshalling functions, software version v14.3 or later must be installed.

Can the device be used in hazardous environmental areas?

Yes, the module is certified for installation within hazardous areas under FM/cFM Class I, Division 2, Groups A, B, C, D (T4 temperature rating) as well as ATEX/IECEx Zone 2 setups.

What is the function of the internal non-volatile memory?

The internal NVM RAM fully retains the active control strategies configuration. In the event of an unexpected power failure, this memory ensures the device can execute a completely autonomous cold restart once power returns.

Where should the module be mounted on its carrier?

The module must be explicitly installed on the designated right slot position of an M-series 2-wide Power/Controller Carrier.
