Emerson VS3202 KJ2201X1-BA1 DeltaV SIS Logic Solver Module

SKU VS3202 KJ2201X1-BA1

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Emerson
Product No.: VS3202 KJ2201X1-BA1
Country of origin:United States
Product Type: Logic Solver Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 500g
Dimensions: 8.3cm x 12.5cm x 10.5cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Emerson VS3202 KJ2201X1-BA1 is a safety-certified safety instrumented system module engineered as part of the DeltaV SIS platform. This logic solver, also designated as the SLS 1508, provides dedicated safety loop execution independent from standard regulatory control layers while remaining integrated within the configuration and diagnostic environment. The module communicates with intelligent field sensors via the HART protocol to diagnose faults before they manifest as process interruptions. It is built to fulfill safety instrumented functions across modern processing facilities, ensuring continuous process availability and asset protection.

Features

Decoupled execution system separating emergency safety logic from regulatory process control
Integrated safety bus capabilities managing field level instrumentation directly via HART diagnostics
Scalable architecture allowing step-by-step sizing adjustments to fit individual application footprints
Hot-swappable hardware design permitting the online addition of redundant safety components

Applications

Safety Instrumented Systems (SIS) logic solving loops
Emergency Shutdown (ESD) architectures
Fire and Gas (F&G) management integration
High-integrity burner management and protection systems

Ordering Information

Description	Model Number
DeltaV SLS 1508 Redundant Logic Solver – includes Terminal Block VS3202	VS3202 / SLS 1508

Technical Specifications

Power Specifications

Parameter	Specification
Local Bus Power	24 VDC at 1 A
Field Power	4 A (maximum)

Environmental Specifications

Parameter	Specification
Ambient Temperature	-40 degC to +70 degC
Shock	10g 1/2 Sinewave for 11msec
Vibration	1mm Peak to Peak from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz
Airborne Contaminants	ISA-S71.04-1985 Airborne Contaminants Class G3
Relative Humidity	5 to 95% Non-Condensing

Installation Guidelines

Ensure field power supplied to this device, either at the field terminal or as bussed field power through the carrier, is completely removed before connecting or disconnecting the module.
Do not remove or insert the unit with system power energized unless the area is verified to be non-hazardous.
Mount the module within environments complying with ISA-S71.04-1985 Class G3 standards to prevent corrosion from airborne contaminants.
Verify all redundant wiring and bus configurations are completed prior to initial software commissioning or online extension steps.

Compliance and Certifications

ATEX: II 3G Ex ec IIC Gc (FM16ATEX0056U)
UKEX: Ex ec IIC Gc (FM21UKEX0017U)
FM Approved: CL. I Div. 2 GP. A,B,C,D; CL. I Zone 2 AEx/Ex ec IIC Gc (FM17US0286U, FM17CA0145U)
TÜV NORD: IEC 61508:2000 SIL 3 Capability
CE: Certified

FAQ

Can this safety module be removed or inserted while the system is energized?

The module cannot be removed or inserted with system power energized unless the surrounding environment is explicitly verified to be non-hazardous.

What is the certified ambient operating temperature limit for the device?

The device is certified to operate within an ambient temperature range of -40 degC to +70 degC.

What standard must be met regarding airborne contamination at the installation site?

The installation site should satisfy the requirements for an ISA-S71.04-1985 Airborne Contaminants Class G3 environment.
