HIMA F4204 Planar F Safety-related 8-channel Digital Output Module

SKU F4204

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: HIMA

  • Product No.: F4204

  • Country of origin:Germany

  • Product Type: Digital Output Module

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 400g

  • Dimensions: 3.2cm x 21cm x 13.3cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The F4204 is a safety-related 8-channel digital output module developed for integration into Planar F automation architectures. This unit works within high-reliability plant setups to handle discrete digital output routing for safety loops. Running on a nominal supply voltage of 24 V DC, the device bridges the central control subsystem with critical field instrumentation actuators. The entire hardware construction is built over a standard European size printed circuit board (PCB) geometry to guarantee a stable mechanical fit within official system sub-racks while verifying vital plant logic safety goals.

Features

  • Provides 8 discrete safety-related digital output pathways
  • Manufactured using a standard European size PCB mechanical structural shape
  • Full system capability mapping directly into standard Planar F controller racks
  • Carries the designated manufacturing certification mark label "Safety in electronics"

Applications

  • Safety-related automation plant loop setups
  • Emergency shutdown (ESD) discrete command management
  • Critical actuator and interlock safety logic interfacing

Technical Specifications

Parameter Value
Manufacturer HIMA Paul Hildebrandt GmbH + Co. KG
Model F4204
System Planar F
Module Type Safety-related 8-channel Digital Output Module
Nominal Supply Voltage 24 V DC
Structural Shape European standard size pcb

Installation Guidelines

  • Chassis Earth Grounding: Secure the primary sub-rack frame to the central plant reference grounding bar before positioning the input board.
  • PCB Rail Alignment: Slide the European standard size PCB evenly down the specified card cage slots to prevent mechanical strain on the structural contacts.
  • Connection Inspection: Verify field sensor line polarities prior to locking down interface linkages and restoring loop operational power.

Compliance and Certifications

  • 73/23/EEC Low voltage Directive
  • DIN V 19251:1995
  • DIN V 19250:1994
  • VDE 0116:1989
  • DIN V VDE 0801:1990 and Amendment A1:1994
  • CDV IEC 1508, parts 1-7, (SIL 1-3), (as applicable)
  • prEN 50178:1996
  • DIN VDE 0160 and A1:1989
  • IEC 68 parts 2-1, 2-2, 2-3, 2-6
  • EN 50081-2:1993
  • EN 50082-2:1994
  • EN 55011:1991
  • TÜV PRODUCT SERVICE GmbH Certificate (Report No. HB63893C Rev. 4.1 / U 93 10 19183 009)

FAQ

What is the nominal operating voltage required for this output module?
The module operates with a nominal supply voltage of 24 V DC.

How many safety channels are available on this device?
The device features 8 safety-related digital output channels.

What mechanical board size format does this module utilize?
The module is designed using the standard European size printed circuit board (PCB) structural shape.
