Honeywell FS-PDC-IOR05A Power Distribution Cable

SKU FS-PDC-IOR05A

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Honeywell
Product No.: FS-PDC-IOR05A
Country of origin:United States
Product Type: Power Distribution Cables
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 400g
Dimensions: 24 x 18.8 x 6.5 cm (packaged)
Shipping port: Xiamen
Warranty: 12 months

Description

The Honeywell FS-PDC-IOR05A is a high-reliability power distribution cable engineered specifically for integration within Honeywell Safety Manager industrial safety systems. Designed to deliver stable and consistent operating power, this specialized cabling assembly connects power infrastructure directly to critical input and output modules housed within the IOCHAS-0003R chassis architecture.

Constructed utilizing specialized SAB 2040707 cabling, the FS-PDC-IOR05A features precision-engineered multi-conductor wiring and robust industrial connectors to ensure uninterrupted power delivery and maximum signal integrity in demanding process environments. Its purpose-built design facilitates seamless expansion, maintenance, and reliable electrical distribution across safety-instrumented systems.

Features

Engineered specifically for Honeywell Safety Manager system architectures
Supports critical I/O modules housed in IOCHAS-0003R chassis configurations
Built using high-grade SAB 2040707 industrial cable specification
Equipped with an 8-pole Weidmuller BLC 5.08/8 BR pin header and DFFC 0.5 - 1.0 SN E compatible pins
Maintains rigorous electrical continuity and mechanical durability under operational stress

Applications

Safety Instrumented Systems (SIS)
Emergency Shutdown Systems (ESD)
Critical process control and automation power distribution
Safety Manager hardware chassis expansion and maintenance

Technical Specifications

Parameter	Specification
Manufacturer	Honeywell
Product Type	Power Distribution Cable
Series	Safety Manager
Exact Model	FS-PDC-IOR05A
Compatible Chassis	IOCHAS-0003R
Cable Type	SAB 2040707
Conductor Configuration	7 x 0.75 mm²
Cable Length	2.45 meters
Connector Type	8-pole pin header (Weidmuller BLC 5.08/8 BR with DFFC 0.5 - 1.0 SN E pins)
Country of Origin	USA
Net Weight	0.4 kg
Dimensions	24 x 18.8 x 6.5 cm (packaged)

Connections / Interfaces

Interface	Function
Weidmuller BLC 5.08/8 BR (8-pole pin header)	Primary termination for system power distribution and chassis interconnection
SAB 2040707 Conductor Core (7 x 0.75 mm²)	Carries operational power and control signals between system nodes

Installation Guidelines

Verify the exact model number (FS-PDC-IOR05A) and inspect the cable assembly for any signs of transit damage before installation.
Ensure all associated Honeywell Safety Manager chassis and power supply units are fully de-energized and locked out prior to handling cables.
Route the 2.45-meter cable carefully through standard industrial cable trays, avoiding sharp bends or pinch points.
Secure the 8-pole Weidmuller connector firmly into the designated port on the IOCHAS-0003R chassis.
Confirm mechanical retention and electrical continuity before restoring system power and initiating standard system diagnostics.

FAQ

What systems are compatible with the Honeywell FS-PDC-IOR05A?

The Honeywell FS-PDC-IOR05A power distribution cable is designed specifically for use with Honeywell Safety Manager industrial safety systems and supports modules housed in the IOCHAS-0003R chassis.

What are the core physical specifications of the FS-PDC-IOR05A?

The Honeywell FS-PDC-IOR05A features a length of 2.45 meters, utilizes SAB 2040707 cable with 7 x 0.75 mm² conductors, and incorporates an 8-pole Weidmuller BLC 5.08/8 BR pin header.

What is the primary function of this cable?

The Honeywell FS-PDC-IOR05A delivers stable and consistent operating power between system architecture and critical input/output modules within safety-instrumented environments.

How should the FS-PDC-IOR05A be installed?

Ensure the target Honeywell Safety Manager chassis is fully de-energized, inspect the cable for damage, route it securely avoiding sharp bends, and firmly engage the 8-pole Weidmuller connector into the designated chassis port.
