CPM1A-40CDT-D-V1

Omron

Omron CPM1A-40CDT-D-V1 SYSMAC CPM1A Micro PLC CPU Unit

SKU CPM1A-40CDT-D-V1

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: CPM1A-40CDT-D-V1
  • Origin Japan
  • Product Type: Programmable Logic Controllers
  • Payment: T/T, Western Union
  • Weight: 1.5 kg
  • Dimensions: 90 mm x 150 mm x 50 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Programmable Logic Controllers SYSMAC
Quantity
Call sales Contact

Product Description

Description

Designed for compact, localized machine control, the Omron CPM1A-40CDT-D-V1 micro controller functions as a reliable, high-performance industrial programmable logic controller (PLC) within the SYSMAC CPM1A family. This CPU unit integrates high-density digital I/O with built-in advanced functions, making it a highly efficient solution for space-constrained control panels.

The unit features 24 inputs and 16 transistor outputs, enabling immediate management of multiple field devices without requiring external expansion. For more complex automation architectures, the CPU supports the connection of up to three expansion units. With dedicated high-speed processing capabilities, including an encoder input and a pulse output, it provides precise timing and position control for modern machinery.

Features

  • Integrated high-density I/O footprint featuring 24 DC inputs and 16 NPN transistor outputs.
  • Fast execution speed ranging from 0.72 microseconds to 1.72 microseconds for logic processes.
  • Expandable hardware configuration supporting up to three expansion I/O modules.
  • Built-in high-speed counter (encoder input) capable of processing frequencies up to 5 kHz.
  • Integrated single-phase pulse output rated up to 2 kHz for simplified motion and positioning tasks.
  • Reliable solid-state transistor (sink type) outputs suitable for high-frequency switching applications.

Applications

  • Packaging and labeling machinery
  • Conveyor and material handling systems
  • Small-scale pumping and water treatment control panels
  • Automated assembly systems and tooling machinery

Technical Specifications

Manufacturer Omron
Part Number / Model CPM1A-40CDT-D-V1
Series SYSMAC CPM1A
Power Supply Voltage 20.4 to 26.4 VDC
Total Built-In I/O 40 points (24 Inputs, 16 Outputs)
Input Type 24 VDC Inputs
Output Type Transistor (Sink/NPN type)
Program Capacity 2 kWords
Data Memory Capacity 1 kWords
Logic Execution Speed 0.72 us to 1.72 us
High-Speed Inputs 1 Encoder Input (5 kHz)
Pulse Outputs 1 Pulse Output (2 kHz)
Maximum Expansion Up to 3 expansion units
Dimensions (H x W x D) 90 mm x 150 mm x 50 mm
Shipping Weight 1.5 kg

Installation Guidelines

  • Mounting: Install on a standard 35mm DIN rail or secure directly to a flat panel using the integrated mounting screw holes. Ensure the unit is mounted horizontally to promote optimal heat convection.
  • Wiring: Connect the 24 VDC power supply source only to the designated DC power terminals. Separate input/output wiring from high-voltage power lines to minimize electromagnetic interference.
  • Grounding: Connect the functional ground terminal to a dedicated ground path with a resistance of 100 ohms or less using appropriate gauge copper wiring.
  • Ventilation: Maintain a minimum clearance of 50 mm above and below the controller to ensure proper air circulation and thermal management within the enclosure.

Compliance and Certifications

  • CE compliant
  • UL and cUL listed
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the power supply requirement for the Omron CPM1A-40CDT-D-V1?
The module requires a 24 VDC power supply, with an acceptable operating range of 20.4 to 26.4 VDC.
What type of outputs does this CPM1A controller feature?
It is equipped with 16 solid-state transistor outputs configured as sink type (NPN).
Can I expand the I/O capacity of the CPM1A-40CDT-D-V1?
Yes, this PLC CPU unit supports the addition of up to 3 expansion I/O modules.
Does this unit support high-speed processing or encoder feedback?
Yes, it features 1 built-in encoder input (high-speed counter) rated at 5 kHz and 1 pulse output rated at 2 kHz.
