Schneider ATV12PU15M3 Altivar 12 Variable Frequency Drive

SKU ATV12PU15M3

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV12PU15M3
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 1.3 kg
Dimensions: 18,7cm x 18,7cm x 18cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATV12PU15M3 is a compact frequency converter from the Altivar 12 range, manufactured by Schneider Electric. Designed for high-performance motor management in 3-phase applications, this drive is rated for a power capacity of 0.75 kW and operates within a supply voltage range of 200–240 V.

Engineered for reliability and ease of use, the ATV12PU15M3 is mounted on a base plate for stability, making it an excellent solution for space-constrained industrial setups. The drive features advanced diagnostic capabilities and an intuitive interface, facilitating proactive maintenance and optimal energy efficiency. It is a dependable choice for modernizing motor control systems and improving overall operational performance in light-duty industrial machinery.

Features

Altivar 12 series frequency converter
Power rating: 0.75 kW
Supply voltage: 200–240 V (3-phase)
Compact, base-plate mounted design
User-friendly interface with advanced diagnostics
Optimized for energy efficiency and reliable motor control

Applications

Small-scale pump and fan systems
Conveyor systems and material handling
Centrifugal machines and mixers
General industrial machinery requiring variable speed control

Technical Specifications

Feature	Specification
Brand	Schneider Electric
Range	Altivar
Subrange	12
Product Type	Variable Frequency Drive
Power Rating	0.75 kW
Supply Voltage	200–240 V (3-phase)
Weight	1.30 kg
Dimensions	18.70 cm x 18.70 cm x 18.00 cm
Product Phase	Active
Commodity Code	85044095
Export Control (ECCN)	N

Installation Guidelines

Mounting: Secure the base-plate mounted drive in a clean, ventilated area within an industrial enclosure. Ensure adequate clearance for airflow.
Wiring: Connect the 3-phase power supply and motor leads to the appropriate terminals. Utilize shielded cables for motor connections to minimize electromagnetic emissions.
Grounding: A reliable connection to the system’s protective earth (PE) busbar is mandatory to ensure safety and signal integrity.
Configuration: Use the integrated interface to set parameters for acceleration/deceleration, torque, and speed limits based on the application’s load profile.
Maintenance: Regularly check electrical connections for tightness and ensure the drive’s air intake is clear of dust and debris to maintain effective cooling.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the power rating of this Altivar 12 drive?

The ATV12PU15M3 is rated for 0.75 kW.

Is this drive suitable for 3-phase applications?

Yes, this model is designed specifically for 3-phase motor management.

What is the supply voltage for this unit?

It operates on a 200–240 V supply.

Is this product still in active production?

Yes, the ATV12PU15M3 is currently in the Active stage of its lifecycle.
