Schneider Electric ATV212WU22N4 Altivar 212 Variable Frequency Drive

Description

The ATV212WU22N4 is a 2.2 kW industrial frequency controller designed for reliable motor management in demanding production environments. This variable frequency drive provides precise speed regulation and energy efficiency for automation systems utilizing a 480V three-phase input. Built with EMC class C2 compliance, the ATV212WU22N4 minimizes electromagnetic interference to ensure stable operation alongside sensitive equipment. Housed in an IP55-rated enclosure, it provides robust protection against dust and water ingress, making it well-suited for installation in challenging industrial settings. Project managers and production leaders rely on this controller for dependable motor speed control and streamlined operational performance.

Features

• 2.2 kW power rating for three-phase 480V operation
• Precise speed regulation and energy-efficient motor management
• EMC class C2 compliance for reduced electromagnetic interference
• IP55-rated enclosure providing dust and water protection
• Designed for demanding automation and production environments

Applications

• HVAC systems and air handling units
• Pumping stations and water treatment facilities
• Conveyor systems and material handling equipment
• Industrial fan and compressor control

Technical Specifications

Installation Guidelines

• Ensure proper panel mounting within an environment matching the IP55 enclosure rating requirements.
• Route power and control cables carefully to maintain EMC class C2 compliance and minimize interference.
• Verify adequate ventilation space around the drive to support reliable thermal management during operation.
