Mitsubishi Electric FR-F840-00620-2-60 F800 Series High Performance Inverter

Apenas 10 item(ns) restante(s) em estoque

Fabricante: Mitsubishi Electric
Nº do Produto: FR-F840-00620-2-60
País de origem:Estados Unidos
Tipo de Produto: Variable Frequency Drives
Pagamento: T/T, Western Union
Peso: 15000g
Porto de embarque: Xiamen
Garantia: 12 meses

Ver detalhes completos

Description

Engineered specifically for heavy-duty fan and pump speed control, the Mitsubishi Electric FR-F840-00620-2-60 is a high-performance variable frequency drive belonging to the high-efficiency F800 Series. This unit operates on a three-phase 380V to 500V supply and is configured with standard control features optimized for energy-saving industrial applications. The FR-F840-00620-2-60 model includes a specialized protective circuit board coating to withstand demanding environmental conditions while omitting plated conductors. It features an integrated forced air-cooling system and complies with the IP21 environmental protective structure, making it ideal for clean, enclosed panel installations.

Key Features

Advanced Energy Saving: Built-in optimization algorithms reduce power consumption during variable torque applications.
Enhanced Environmental Resistance: Features protective conformal coating on internal printed circuit boards.
Flexible Input Support: Accommodates a wide input voltage fluctuation range of 323V to 550V AC.
Integrated Cooling: Equipped with active forced air cooling to maintain thermal stability under continuous operation.
IP21 Protection: Designed as an enclosed-type structure suitable for vertical panel mounting.

Applications

Industrial ventilation systems and large-scale exhaust fans.
Water supply, waste-water processing, and industrial pumping networks.
Commercial HVAC air handling units and cooling towers.
Boiler draft fans and secondary cooling loops in manufacturing plants.

Technical Specifications

Manufacturer	Mitsubishi Electric
Model Number	FR-F840-00620-2-60
Series	F800 Series
Voltage Class	400 V Class
Rated Input AC Voltage	Three-phase 380 to 500 V, 50 Hz / 60 Hz
Permissible AC Voltage Fluctuation	323 to 550 V, 50 Hz / 60 Hz
Permissible Frequency Fluctuation	+/- 5%
Structure/Functionality	Standard Model
Inverter Rated Current Code	00620
Control Specification Type	-2 (CA Type)
Circuit Board Coating	With Conformal Coating
Plated Conductor	Without Plated Conductor
Protective Structure	Enclosed Type (IP21 / IEC 60529)
Cooling System	Forced Air Cooling
Net Weight	15.0 kg
Shipping Weight (Calculated)	17.0 kg

Empirical Engineering Insights

Alternative Models & Compatibility

The "-2-60" suffix indicates that this model features coated internal boards and no plated conductors. It can directly replace standard Mitsubishi F800 units with matching current and voltage profiles in environments with elevated moisture or non-corrosive dust. If migrating from older F700 series models, check terminal space alignments as physical dimensions and parameter mappings have updated.

Application Pitfalls & Engineering Notes

Ensure the forced air-cooling fan intake and exhaust paths remain completely unobstructed. In heavy industrial enclosures, thermal dissipation is vital; the unit must be derated if operating in ambient temperatures continuously exceeding 40 degC inside tightly packed panels.

Commissioning & Wiring Tips

Always separate control circuit cables from main power cables to prevent electromagnetic coupling. Use shielded cables for analog inputs (terminal 2 and 4 references) and ensure the shield is grounded at the inverter-end ground plate only to eliminate ground loop noise.

Installation Guidelines

CRITICAL WARNING

Before beginning any installation, maintenance, or wiring procedures, isolate the primary input power supply. Wait at least 10 minutes after power-off to allow internal DC bus capacitors to discharge safely below 50V. Verify with a calibrated multimeter before touching internal terminals.

Mount the inverter vertically on a flat, non-flammable surface (such as a metal plate) to maximize heat dissipation from the rear heatsink.

Connect the physical protective earth (PE) ground to the designated ground terminal before wiring mains power lines to R/L1, S/L2, and T/L3.

Connect output motor cables strictly to terminals U, V, and W. Do not connect mains utility power to these output terminals, as doing so will permanently destroy the inverter.

Key Features:

#F800 Series #Variable Frequency Drives

What does the -2-60 suffix mean on this model?

The -2-60 suffix denotes the CA specification type, featuring internal printed circuit board (conformal) coating for protection against dust and moisture, while omitting copper-plated conductors.

What is the permissible voltage fluctuation range?

This inverter operates on a three-phase nominal input of 380V to 500V AC, with a permissible input voltage fluctuation range of 323V to 550V AC at 50/60 Hz.

What cooling configuration does this inverter utilize?

It relies on an integrated active forced air-cooling system to maintain safe operational temperatures inside the chassis.
