BECKHOFF C9900-F942 Control Panel DVI/USB Extended Interface

Description

Designed to facilitate reliable, long-distance signal transmission, the BECKHOFF C9900-F942 interface connection allows for the remote operation of Beckhoff multi-touch built-in Control Panels. This system integrates DVI/USB Extended (DVI-E and USB-E 2.0) technology, enabling high-performance visual display and touch functionality at extended distances from the industrial PC without signal degradation.

The unit supports robust communication over distances up to 50 meters, translating standard graphics and USB inputs into extended-range industrial signals. Featuring a front-side IP65 ingress protection rating when properly built-in, this interface module is constructed to withstand the rigorous demands of industrial automation environments, ensuring reliable human-machine interface performance in harsh settings.

Features

• DVI-E and USB-E 2.0 signal extension up to 50 meters from the industrial PC.
• High-speed USB-E 2.0 transmission rate up to 480 Mbit/s.
• Standard DVI input compatibility with standard PC DVI outputs.
• Robust front-side IP65 protection rating against dust and water jet entry.
• Pull-out clamping levers for quick and reliable panel installation.

Applications

• Heavy machinery control panels.
• Automotive assembly line HMIs.
• Food, beverage, and packaging machinery interfaces.
• Remote visualization in hazardous or washdown industrial areas.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Ensure the panel cutout dimensions match the specific display variant (from 7-inch to 24-inch) before mounting.
• Utilize the integrated pull-out clamping levers to secure the unit within the cabinet wall or panel enclosure without loose installation hardware.
• Run high-quality shielded CAT cable for the RJ45 USB-E 2.0 connection, keeping it separated from high-voltage AC cabling to prevent EMI.
• Connect the unit to a stable, industrial-grade 24 V DC power supply. Verify proper chassis grounding to preserve signal integrity over the 50 m transmission path.

Compliance and Certifications

• CE
