BECKHOFF C9900-E545 Control Panel Accessories Push-Button Extension

Name: BECKHOFF C9900-E545 Control Panel Accessories Push-Button Extension
Brand: BECKHOFF
SKU: C9900-E545

Stokta sadece 10 adet kaldı

Üretici: BECKHOFF
Ürün No.: C9900-E545
Menşei ülke:Almanya
Ürün Türü: Push-Button Extensions
Ödeme: T/T, Western Union
Ağırlık: 5000g
Boyutlar: drawings with dimensions of the push-button e x tensions as AutoCAD DXF file
Gönderim limanı: Xiamen
Garanti: 12 ay

Description

Designed to integrate directly onto the right-hand side of compatible operator interfaces, the C9900-E545 provides supplementary physical operator control elements for CP6xxx and CP7xxx series Control Panels and Panel PCs. This hardware extension is engineered specifically for 15-inch displays configured without integrated keyboards, delivering structured control feedback in demanding industrial environments.

The layout incorporates 16 illuminated push-buttons alongside a dedicated safety element. Operator signals utilize a dual-transmission design: primary control transmission and signal lamp illumination route via CP-Link or USB interfaces, while a terminal strip allows secondary hardwiring of normally-open contacts for critical process operations. Customizable label inserts permit site-specific marking of individual buttons to align with plant system configurations.

Features

Compatible with right-side mounting on 15-inch CP6x02-00xx and CP7x02-00xx panels.
Equipped with 16 square push-buttons (30 x 30 mm) featuring integrated signal lamps.
Includes 1 standard-compliant emergency stop button for direct integration into safety circuits.
Dual-contact output design: signals transmit via digital interface (CP-Link or USB) and via secondary direct terminal-row connection.
Removable caps enable custom physical labeling of all push-buttons.

Applications

Human-Machine Interface (HMI) expansion for CNC and machine tool control.
Automotive assembly line operator stations.
Specialty machine manufacturing requiring localized tactile controls and emergency stop functions.

Technical Specifications

ParameterSpecification

Manufacturer	BECKHOFF
Part Number / Model	C9900-E545
Compatibility	CP6xxx and CP7xxx series Control Panels / Panel PCs (15-inch display without keyboard)
Mounting Location	Right-hand side of the host panel
Push-Buttons	16 x illuminated push-buttons (Siemens Signum square, 30 x 30 mm)
Emergency Stop Switch	1 x Siemens Signum emergency stop (directly wireable)
Signal Interface	CP-Link or USB (for primary contacts and signal lamps)
Auxiliary Interface	Terminal row (for hardwiring second normally-open contacts)
Shipping Weight	5 kg

Connections and Interfaces

Interface Type	Function Assignment
USB / CP-Link Connection	Primary normally-open (NO) contact transmission and signal lamp control power.
Internal Terminal Strip	Direct connection points for secondary normally-open (NO) contacts.
Emergency Stop Terminals	Dedicated dry contact points for direct safety circuit integration.

Installation Guidelines

Ensure all power is disconnected from the main Control Panel or Panel PC prior to mounting the extension.
Align the structural fastening points on the right flange of the 15-inch panel housing to secure the mechanical link.
Route the USB/CP-Link internal cables to the host motherboard connectors without pinching.
Observe regional safety standards when wiring the emergency stop switch to the main safety monitoring relay.

Key Features:

#BECKHOFF Control Panels #Push-Button Extensions

Which specific panels are compatible with the BECKHOFF C9900-E545?

The C9900-E545 is designed for mounting on the right-hand side of BECKHOFF CP6xxx and CP7xxx series Control Panels and Panel PCs with 15-inch displays that do not contain an integrated physical keyboard.

Can the emergency stop button be integrated into a safety PLC loop?

Yes, the emergency stop switch is designed to be directly wireable via independent terminals, allowing integration into standard safety relays or safety PLC architectures.

How are the 16 signal lamps powered and controlled?

The signal lamps are controlled and powered exclusively through the USB or CP-Link connection linked to the host system.
