Contrôle de température Danfoss 060L313066 KPS80

Il ne reste que 10 article(s) en stock

Fabricant : Danfoss
N° de produit : 060L313066
Pays d'origine :États-Unis
Type de produit : Interrupteur de température
Paiement : Virement bancaire, Western Union
Poids : 2500g
Port d'expédition : Xiamen
Garantie : 12 mois

Description

The Danfoss 060L313066 is a KPS80 series temperature control unit engineered for robust monitoring and regulation in demanding industrial environments. This temperature switch features an adjustable differential and is equipped with a 5000 mm capillary tube, providing flexibility for remote sensing applications. Designed for high reliability, the unit utilizes an adsorption charge and includes an SPDT gold contact configuration, making it suitable for low-current control circuits as well as standard switching operations. The housing is protected with armoring and includes a metal cable gland with a Pg 13.5 screwed cable entry for secure electrical connection.

Features

Model: KPS80 Temperature Control
Sensing Range: 70 to 120 degC
Capillary Tube Length: 5000 mm
Contact Configuration: SPDT Gold
Enclosure Protection: Armoring included
Electrical Connection: Screwed cable entry (Pg 13.5)
Connection Type: M 18 x 1.5 for pocket or hose
Charge Type: Adsorption

Applications

Industrial boilers and heat exchangers
Marine cooling and heating systems
Process plant temperature monitoring
Hydraulic power units
Compressor temperature regulation

Technical Specifications

Feature	Specification
Manufacturer	Danfoss
Product Model	060L313066
Temperature Range	70 to 120 degC
Ambient Temperature	-40 to 70 degC
Capillary Tube Length	5000 mm
Differential Type	Adjustable
Contact Rating (AC1)	10 A, 440 V
Contact Rating (AC3)	6 A, 440 V
Contact Rating (AC15)	4 A, 440 V
Contact Rating (DC13)	12 W, 220 V
Gold Contact Range	1 to 30 mA, 5 to 30 V
Weight	2.5 Kg

Installation Guidelines

Mounting: Ensure the sensing element is installed in a location representative of the process temperature. Secure the capillary tube to prevent mechanical damage or excessive vibration.
Connection: The M 18 x 1.5 connection is designed for use with a thermowell (pocket) or hose to ensure accurate temperature transfer and environmental sealing.
Cable Entry: Utilize the provided Pg 13.5 metal cable gland to maintain the integrity of the electrical connection against dust and moisture.
Calibration: Adjust the temperature setting and differential according to the specific requirements of the process loop.
Ambient Limits: Ensure the ambient temperature of the control housing remains within the -40 degC to 70 degC range. Note that the unit can withstand 80 degC for a maximum of 120 minutes.

Key Features:

#Danfoss KPS Series #Temperature Switches

What is the primary application for the gold contacts in this unit?

The SPDT gold contacts are specifically designed for low-current applications, typically ranging from 1 mA to 30 mA at 5 V to 30 V, ensuring reliable switching in sensitive control circuits.

Can this unit withstand ambient temperatures above 70 degC?

The operating ambient temperature range is -40 degC to 70 degC. It can withstand a maximum of 80 degC for up to 120 minutes.

Does this model include a protection pocket?

The unit features an M 18 x 1.5 connection for a pocket or hose, but the pocket itself must be sourced according to specific installation requirements.

What is the function of the adsorption charge?

The adsorption charge is the sensing medium inside the capillary system that reacts to temperature changes to actuate the switch contact.
