NS5-TQ10B-V2 | Omron | Terminaux programmables série NS

Description

Designed for robust human-machine interaction, the Omron NS5-TQ10B-V2 serves as a high-performance operator interface within the NS-Series Programmable Terminals portfolio. This compact unit integrates a 5.7-inch high-luminance TFT color display, providing crisp visualization of automation processes and machine parameters. Engineered for seamless integration into factory floor environments, this module interfaces directly with Sysmac controller networks and standard PLCs using optimized serial protocols.

The unit features a responsive touch panel configuration designed for industrial longevity, supporting detailed custom graphic layouts, alarm monitoring, and trend logging. This specific variant, designated with the model suffix NS5-TQ10B-V2, features a standard black bezel housing and supports serial interfaces while omitting onboard Ethernet connectivity, making it an economical choice for localized control systems where dedicated serial communications are utilized.

Features

• High-contrast 5.7-inch TFT LCD color display.
• Clear QVGA resolution supporting detailed graphic objects and clean text rendering.
• Robust touchscreen interface designed for heavy industrial use.
• Built-in serial communication ports for direct connection to host controllers.
• Compact physical footprint with a shallow mounting depth suitable for space-constrained enclosures.
• Support for standard Omron Smart Active Parts (SAP) library to reduce HMI screen development time.

Applications

• Packaging and labeling machinery control.
• Material handling and conveyor line monitoring.
• Specialized assembly equipment workstations.
• Water treatment and chemical dosing panel control.
• HVAC and building management system visualization.

Technical Specifications

Connections and Interfaces

Installation Guidelines

To ensure proper performance and long service life, mount the NS5-TQ10B-V2 in an industrial control panel with a cutout matching the standard panel dimensions of 184 mm (width) x 131 mm (height). Allow a minimum of 100 mm of clearance space around the back of the terminal for adequate air circulation and cable routing. Secure the terminal tightly using the provided mounting brackets to maintain its front-panel sealing rating. Ensure proper grounding by connecting the functional ground terminal to a dedicated low-impedance ground point.
